DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 79
DCA-25USIXF/DCA-25USI2XF— FUEL TANK ASSY.
FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M1363001302 FUEL TANK 1
2 0605505072 FUEL TANK CAP 1
3 0605501098 FUEL SENDER UNIT 1
4 0605516090 GASKET 1
5 0027104016 MACHINE SCREW 5
6 M1363300314 TANK SUPPORT 2
7 0016908035 HEX, HEAD BOLT 8
8 0602022791 HOSE JOINT 2
9 0191301200 VENT HOSE 1
10 0605515109 HOSE BAND 7
11 8943672922 FUEL FILTER ASSY. ...................................... 1 ........... REPLACES P/N 0602042202
11A 8943692993 CARTRIDGE, FUEL FILTER .......................... 1 ........... REPLACES P/N 0602042700
12 M1368700004 BRACKET, FUEL FILTER 1
13 0016908020 HEX, HEAD BOLT 4
14 8970398340 FUEL PUMP ................................................... 1 ........... REPLACES P/N 0602023177
14A 8944370220 FUEL FILTER, KIT 1
15 0016906025 HEX, HEAD BOLT 2
16 M1363400404 PICKUP TUBE 2
17 0603306863 BUSHING 2
18 0602022971 HOSE JOINT 2
19 0191200330 SUCTION HOSE 1
20 0191200200 SUCTION HOSE 1
21 0191201300 SUCTION HOSE 1
22 0191200800 RETURN HOSE 1
23 0605515198 HOSE BAND 3
24 0603306797 PLUG, 1-1/2 1
25 0222100550 TANK SHEET 4
FUEL TANK ASSY.
