DCA25USIXF/DCA25USI2XF — OPERATION AND PARTS MANUAL — REV. #2 (07/26/11) — PAGE 87
ENCLOSURE ASSY. (DCA25USIXF ONLY)
NO. PART NO. PART NAME QTY. REMARKS
1 M1413003902 BASE 1
1A M1493000704 ACOUSTIC SHEET 1
2 M1413100003 ENVIRONMENTAL TANK 1
3 0603306797 PLUG, 1-1/2 1
4 0016910030 HEX, HEAD BOLT 6
5 M1424000502 FRONT FRAME 1
5 M1413600004 DUCT 1
6 0016908020 HEX, HEAD BOLT 6
7 M1423002402 FRONT FRAME 1
7A M1493108303 ACOUSTIC SHEET 1
8 0601850151 GROMMET 1
9 M1423202602 FRONT DUCT 1
9A M1493108003 ACOUSTIC SHEET 1
10 0601851740 GROMMET 1
11 0601850239 GROMMET 1
12 0016908020 HEX, HEAD BOLT 10
13 0016906020 HEX, HEAD BOLT 1
14 0016908020 HEX, HEAD BOLT 6
15 M1423202704 DUCT COVER 2
16 0016906020 HEX, HEAD BOLT 10
17 M1423202704 DUCT COVER 1
18 0016906020 HEX, HEAD BOLT 5
19 M1424200803 HOSE COVER 1
20 0016906020 HEX, HEAD BOLT 5
21 M1423202003 COVER, FROM FRAME 1
22 M1423202103 FRONT LOUVER 1
23 0016906016 HEX, HEAD BOLT 8
24 0019208020 HEX, HEAD BOLT 5
25 M1433001403 CENTER FRAME 1
26 M1433400003 CENTER FRAME 1
27 0013612030 HEX, HEAD BOLT 4
27A 0040012000 WASHER, LOCK 4
27B 0041212000 WASHER, FLAT 4
28 0013612030 HEX, HEAD BOLT 4
28A 0040012000 WASHER, LOCK 4
28B 0041212000 WASHER, FLAT 4
29 M1443001502 REAR FRAME 1
29A M1493304004 ACOUSTIC SHEET 1
29B M1493305304 ACOUSTIC SHEET 1
30 M1453301703 DUCT COVER 1
30A M1493305304 ACOUSTIC SHEET 1
30B M1493305404 ACOUSTIC SHEET 1
30C M1493305504 ACOUSTIC SHEET 1
DCA25USI2XF — ECLOSURE ASSY.
