Page 56

Expires:3600

Registering to: Sip:80.248.33.37 with the following :

Expires:3600

Account: sipcenter1123 registration succeeded

Account: sipcenter1165 registration succeeded

AC4804[0] is ok

successful

Initialize OSS libraries...OK!

VP v1.40 stack open successfully.

19.4.2

Peer-to-Peer Mode

Peer-to-Peer Mode allows users to call other VoIP devices without the proxy

server. When in Peer-To-Peer mode, SP5001/S will send INVITE message

directly to the destination IP address once the dial is finished. One can use

PhoneBook, which will dial predefined phone number, and press “#” (optional,

to accelerate the dial) as end of dial. Or, users can use SpeedDial button,

which is mapping to user defined PhoneBook, Button1 to PhoneBookIndex1,

and Button2 to PhoneBookIndex2… etc..

To configure Peer-To-Peer Mode in SP5001/S, follow the steps below:

Step 1.

Set Peer-To-Peer Mode, using “h323” command

usr/config$ sip – mode 0

Note: mode 0 is for Peer-To-Peer mode, while mode 1 is for Proxy mode.

Step 2.

Configure PhoneBook, using “pbook” command.

Users can refer to chapter 19.7.9 [pbook] command for more information.

usr/config$ pbook – add name TEST1 ip 10.1.1.1 e164 10
