53
19.3.3 Application Mode Configuration
It is including Basic mode, such as Proxy Server and Peer-to-Peer, and
Advanced mode, IP -Sharing mode. It will be detailed in the next Chapter.
19.3.4 Saving Your Configuration
Save the change of configurations for SP5001/S and apply the new
configurations by rebooting the device.
Step 1. Confirm the changed configurations; input “commit” and press
“enter” to save it.
Step 2. Input “reboot” then press, “enter” to restart SP5001/S.
Step 3. After around 40 seconds, SP5001/S will take effect in new
configurations.
These commands save all system configuration into nonvolatile memory.
Nonvolatile memory refers to the storage of SP5001/S that remains even if its
power is turned of. Run Time (memory) is lost when its power is turned off.
You must use the command to save any configuration that you make,
otherwise it will return to its default setting when it is restarted.
Do not turn off or remove SP5001/S
while saving your configuration.
19.4 Application modes
This section will introduce the four application modes users often use.
Particularly the Proxy and Peer-to-Peer mode are the basic application mode. User
would like to set as advanced application mode, such as PPPoE Mode and Behind
IP-Sharing mode, please refer to the basic application mode for more information.
19.4.1 Proxy mode
Proxy mode means that there will be an intermediate Proxy Server between
SP5001/S and the remote entity. While operating at this mode, SP5001/S will
first register to the Proxy Server located at the ISP side. For the following
operation, it sends the INVITE message to the Proxy Server once you initiate
a session. Then the Proxy server will forward the INVITE message to the right
place. And the Response message from the remote entity will be forwarded
back to you via Proxy server.
Step 1. If you have one or more accounts included user name and
password, you need to configure the accounts using “security”
