13
Step 5. Grounding SP5001/S
If you want to ground SP5001/S then connect a grounded wire to the F.G.
(Frame Ground) of SP5001/S.
1.6 Additional Installation Requirements
In addition to the contents of your package, there are other hardware and software
requirements you need before you can install and use your SP5001/S. These
requirements include:
1. A computer with an Ethernet NIC (Network Interface Card) installed.
2. A computer equipped with communications software configured to the following
parameters:
Ÿ VT100 terminal emulation.
Ÿ 9600 Baud.
Ÿ No parity, 8 Data bits, 1 stop bit, Flow Control set to None.
3. Use Internet Explorer 5.5 and later or Netscape Navigator 6 and later versions.
After SP5001/S is properly set up, you can make future changes to the configuration
through telnet connections.
1.7 Setting Up the TCP/IP Protocol
If you are not sure whether the TCP/IP Protocol has been installed, follow these setups
to check, and if necessary, install TCP/IP onto your PCs.
Step 1. Click the “Start” button, Choose “Settings”, then “Control Panel”.
Double-click the “Network” icon. Your Network window should appear as
follows.
Step 2. Select the “Configuration” tab.
Note:
For Windows 2000 & Windows XP Setting, you will find that they differ with
Windows 98/ME/NT slightly. See the Following for reference.
Click the “Local Area Connection” icon on the lower right hand side of your
desktop screen.
In the “Local Area Connection Status” windows, click the “Properties”
button, and then your Network windows will appear.
There is only one tab, “General”, in the Network window.
