10
1.5 Hardware Specifications
These are the hardware details of SP5001/S.
1.5.1 SP5001/S LEDs
Table 1. SP5001/S LEDs Descriptions
LEDs Functions Status Active Description
On The Power is on
PWR Power Green
Off The Power is off
On The Telephone is Off-Hook.
TEL TEL Red
Off The Telephone is On-Hook.
Slow Blinking Normal mode.
READY Ready Green
Fast Blinking Downloading mode.
On
Proxy mode and has registered to Proxy
server successfully
Blinking
Proxy mode and has not yet registered
to Proxy server.
Downloading mode.
STATUS Status Green
Off Peer-to-Peer Mode.
On
Ethernet connection has been
established
Blinking
Ethernet data is being transmitted /
received.
ACT/LNK LAN Green
Off No connection
On The 100M LAN is connected.
100/10 LAN Green
Off The 10M LAN is connected.
On Transmitting mode is full duplex.
FDX Full / Half Green
Off Transmitting mode is half duplex.
