35
7. SIP Information Screen
Click SIP Configuration in the navigation panel and open the SIP Information Screen.
Figure 18. SIP Information
The following table describes this screen.
Table 4. SIP Information
LABEL DESCRIPTION
RUN Mode Select Proxy mode or Peer-to-Peer mode
Proxy IP Address Set Proxy IP Address in dotted decimal notation e.g.192.168.4.71.
Proxy Port SIP local UDP port number (5060~5070), default: 5060.
Domain Set Domain Name of Proxy Server.
Prefix String Set prefix for gateway to work with proxy server.
Line1 Number Set Line1 Number.
Line1 Account Set Line1 Account Name.
Line1 Password Set Line1 Account Password.
SIP Port Set SIP port number, example 5060.
RTP Port Set RTP port number, example 16384.
Expire Used to inform proxy server the valid duration of the registration
information.
OK Click OK to save your changes back to volatile memory.
