36
8. System Configuration Screen
Click System conf in the navigation panel and open the System Configuration Screen.
Figure 19. System Configuration
The following table describes this screen.
Table 5. System Configuration
LABEL DESCRIPTION
Keypad Type Select In-Band, RFC2833 on DTMF relay type
RFC2833 Payload
Type
RFC2833 Payload Type (range:96~128 inter-used:100,102~105)
FAX Payload Type Set Fax Payload Type (range: 96 or 101, default: 101)
Inter Digit Time Set the DTMF inter digit time (second)
Busy Forward Enable it to route the call to the next line (While the line number is not
matched or engaged)
End of Dial Digit Set end of dial key as NONE, * , or #.
OK Click OK to save your changes back to volatile memory.
