background image

MultiVOIP FX User Guide Technical

Configuration

91

“Regional Parameter” Definitions

Field Name

Values

Description

Standard Tones fields

Type column

dial tone,
ring tone,
busy tone,
unobtainable
tone (fast busy),
survivability
tone,
re-order tone

Type of telephony tone-pair for
which frequency, gain, and
cadence are being presented.

Frequency 1

freq. in Hertz

Lower frequency of pair.

Frequency 2

freq. in Hertz

Higher frequency of pair.


“Regional Parameter” Definitions (cont’d)

Field Name

Values

Description

Standard Tones fields

(cont’d)

Cadence
(msec) On/Off

n/n/n/n
four integer time
values in
milli-seconds;
zero value for
dial-tone
indicates
continuous tone

On/off pattern of tone durations
used to denote phone ringing,
phone busy, connection
unobtainable (fast busy), dial tone
(“0” indicates continuous tone),
survivability, and re-order. Default
values differ for different
countries/regions. Although most
cadences have only two parts (an
“on” duration and an “off”
duration), some telephony
cadences have four parts. Most
cadences, then, are expressed as
two iterations of a two-part
sequence. Although this is
redundant, it is necessary to allow
for expression of 4-part cadences.

Gain 1

gain in dB
+3dB to –31dB
and “mute”
setting

Amplification factor of lower
frequency of pair.
This applies to the dial, ring, busy
and ‘unobtainable’ tones that the
MultiVOIP outputs as audio to the
FXS or FX0 port. Default: -16dB

Gain 2

gain in dB
+3dB to –31dB
and “mute”
setting

Amplification factor of higher
frequency of pair.
This applies to the dial, ring, busy,
and ‘unobtainable’ (fast busy) tones
that the MultiVOIP outputs as
audio to the FXS or FXO port.
Default: -16dB
