MultiVOIP FX User Guide Technical

Configuration

83

FXO Interface: Parameter Definitions*

Field Name

Values

Description

Select Channel

1-2 (MVPFX2-2);
1-4 (MVPFX2-4);
1-8 (MVPFX2-8)

Indicates the voip channel to
which parameter values will be
assigned.

Interface Type

FXO

Enables FXO functionality.

Caller ID fields

Type Bellcore The MultiVOIP currently

supports only one
implementation of Caller ID.
That implementation is Bellcore
type 1 with Caller ID placed
between the first and second
rings of the call.

Enable Y/N

Caller ID information is a
description of the remote
calling party received by the
called party. The description
has three parts: name of caller,
phone number of caller, and
time of call. The ‘time-of-call’
portion is always generated by
the receiving MultiVOIP unit
(on FXS channel) based on its
date and time setup.

In general, the forms of the
‘Caller Name’ and ‘Caller
Phone Number’ differ
depending on the IP
transmission protocol used and
upon entries in the phonebook
screens of the remote (CID
generating) voip unit. For
MVPFX2 units, only the SIP-
related Caller ID options are
available. The CID Name and
Number appearing on the
phone at the terminating FXS
end will come either from a
central office switch (showing a
PSTN phone number), or the
phonebook of the remote (CID
sending) voip unit.
