MultiVOIP FX User Guide Technical

Configuration

85

FXO Interface: Parameter Definitions*

Disconnect Options

Sequence 1

st

tone pair

+
2

nd

tone pair

These are DTMF tone pairs
constitute 2-part sequences that
signal call disconnection.

Values for first tone pair are:
*, #, 0, 1-9, and A-D.

Values for second tone pair are:
none, 0, 1-9, A-D, *, and #.
The tone pairs 1-9, 0, *, and #
are the standard DTMF pairs
found on phone sets. The tone
pairs A-D are “extended
DTMF” tones, which are used
for various PBX functions.

Silence
Detection

Y/N Enables/disables

silence-

detection method of
supervising call disconnection.

Type (of
Silence
Detection)

One-Way or
Two-Way

Disconnection to be triggered
by silence in one direction only
or in both directions
simultaneously.

Timer (for
Silence
Detection)

integer values,
in seconds

Duration of silence required to
trigger disconnection.

Dialing Options

Regeneration Pulse,

DTMF Determines whether digits

generated and sent out will be
pulse tones or DTMF.

Inter Digit
Timer

1 to 10 seconds

This is the length of time that
the MultiVOIP will wait
between digits. When the time
expires, the MultiVOIP will
look in the phonebook for the
number entered.
Default = 2.

Inter Digit
Regeneration
Time

50 to 20,000
milliseconds

The length of time between the
outputting of DTMF digits.
Default = 100 ms.
