Page 20
Command PC & Voip Hookups
MultiVOIP FX Quick Start Guide
20
Quick Hookup for
MVPFX2-2
Console Port Connection
Power Connection
Voice/Fax Channel 1 - 2
Connections
GND
FXS FXO
FX S
PSTN
FXO
FXS
FXS
FXO
FXO
VOICE/FAX 1
WAN
CONSOLE
10/100
RS-232
VOICE/FAX 2
POWER
RJ-11
Connectors
RJ-45
Connectors
WAN/Ethernet Connection
DB-9 Connector
to
Computer Serial Por t
