Phone Book Configuration

MultiVOIP FX User Guide

110

Enter Inbound PhoneBook data for your MultiVOIP. The fields of the Inbound Phone Book Add Entry

screen are described in the table below.

Inbound Phone Book Add Entry screen:

Field Definitions

Field Name

Values

Description

Accept Any
Number

Values

: Y/N

Description:

When checked, “Any Number”

appears as the value in the Remove Prefix
field.
The Any Number feature of the Inbound
Phone Book does not work when an external
routing device is used (Proxy for SIP
protocol).
When no external routing device is used. If
Any Number is selected, calls received from
phone numbers not matching a listed Prefix
(shown in the Remove Prefix column of the
Inbound Phone Book) will be admitted into
the voip on the channel listed in the Channel
Number
field. “Any Number” can be used in
addition to one or more Prefixes.

Remove Prefix

dialed digits

portion of dialed number to

be removed before

completing call to destination

(often a local PBX)

Add Prefix

dialed digits

digits to be added before

completing call to destination

(often a local PBX)

Channel
Number

1-24, or
“Hunting”
or 1-2
or 1-4
or 1-8
depending
on model

Channel number to which the
call will be assigned as it
enters the local telephony
equipment
(often a local PBX).
“Hunting” directs the call to
any available channel.

Description

--

Describes the facility or
geographical location at
which the call originated.

Register with

SIP Proxy

Y/N

*Must be
enabled in
Call
Signaling

Configuration

screen.

When checked, the value in
the Remove Prefix field will
be registered with the
external SIP proxy routing
device. The IP address of the
external routing device must
be set in the Phone Book
Configuration screen.

In a SIP voip system,
gateways can register with
the SIP Proxy.
