MultiVOIP FX User Guide Technical
Configuration
69
Note that Voice/FAX parameters are applied on a channel-by-channel basis. However, once you have
established a set of Voice/FAX parameters for a particular channel, you can apply this entire set of
Voice/FAX parameters to other channels by using the Copy Channel button and its dialog box.
The Voice/FAX Parameters fields are described in the tables below.
Voice/Fax Parameter Definitions
Field Name
Values
Description
Default -- When this button is clicked, all
Voice/FAX parameters are set to their
default values.
Select
Channel
1-2 (FX2-2)
1-4 (FX2-4)
1-8 (FX2-8)
Channel to be configured is selected
here.
Copy
Channel
--
Copies the Voice/FAX attributes of one
channel to another channel. Attributes
can be copied to multiple channels or all
channels at once.
Voice Gain
--
Signal amplification (or attenuation) in dB.
Input Gain
+31dB
to
–31dB
Modifies audio level entering voice
channel before it is sent over the network
to the remote VOIP. The default &
recommended value is 0 dB.
Output Gain +31dB
to
–31dB
Modifies audio level being output to the
device attached to the voice channel. The
default and recommended value is 0 dB.
