Technical Configuration MultiVOIP FX User Guide
60
Telephony Interface Parameters
The following parameters must be known about the PBX or telco central office equipment to which the
analog MultiVOIP will connect:
Phone Parameters
Ask phone company or
telecom manager.
Telephony Interface Parameters:
Record for this VOIP Site
#
• Which interface type is to be used?
FXS _____ FXO _____
• If FXS, determine whether the line will be used for a
phone, fax, or KTS (key telephone system)
• If FXO, determine if line will be an analog PBX
extension or an analog line from a telco central office
Config Info CheckList
Type of Configuration
Info Gathered MultiVOIP
Configuration
screen on which
to enter the Info Info
Obtained
√
Info
Entered
√
IP Info for voip unit
● IP address
● Gateway
● DNS IP (if used)
IP Parameters
Interface Type
(Choices: FXS, FXO)
*In FXO/FXS systems,
channels used for phone,
fax, or key system are
FXS; channels used for
analog PBX extensions or
analog telco lines are
FXO.
Interface
Parameters.
Country Code Regional
Parameters
Reminder: Be sure to Save & Apply after entering configuration values.
