11.3.4 Receive Adjustments
The receive mode is entered by pressing SHIFT + R on the keyboard.
Ensure that the power supply is set to +7.5V.
11.3.4.1 Audio Output Level
Set Test Set RF level to –47dBm, with 1kHz audio modulation at 20dB above nominal. Set the
volume control to maximum and adjust RX_VOL to generate 2.2Vrms audio output level.
Any other adjustments are covered earlier on in this Service Manual.
