SP200/210 Maxon SP200/210 Radio
Issue 1.0
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
03/01
Page 8-13
Category
Code & Part No.
Description
Qty
Location
C
311-069-4
COIL CHIP 0.15UH:NL252018T-R15J
1
L15
C
311-077-1
COIL CHIP 0.68UH:NL252018T-R68J
1
L14
C
311-079-3
COIL CHIP 1.0UH:NL252018T-1R0J
2
L6.18
C
311-170-1
COIL CHIP 1000UH:300SS-102K=CP3
2
L16.17
C
311-297-3
COIL SPRING 3X0.55X5T:L SMD
2
L8.11
C
311-298-4
COIL SPRING 3X0.55X4T:L SMD
1
L7
C
311-323-3
COIL SPRING 2.8X0.4X8T:L
1
L13
C
416-096-C
P.C.B RF 99 X53.3 X1.0 FR4 2/S
1
C
421-204-3
CONNECTOR DF15(0.8)-30DS-0.65V(51)
1
J1
C
422-930-0
SPRING CONNECTOR GW9803302
2
CON1.9
C
450-528-0
VR 20KA TP76NOON
1
VR5
8.4.3 TCXO
Assembly
Category
Code & Part No.
Description
Qty
Location
C
05B-102-4Z
CHIP RESISTOR 1K 1/16W 5% T 1608
1
R10
C
05B-103-5Z
CHIP RESISTOR 10K 1/16W 5% T 1608
1
R9
C
05B-104-6Z
CHIP RESISTOR 100K 1/16W 5% T 1608
2
R13.15
C
05B-122-2Z
CHIP RESISTOR 1.2K 1/16W 5% T 1608
1
R1
C
05B-152-9Z
CHIP RESISTOR 1.5K 1/16W 5% T 1608
1
R16
C
05B-154-1Z
CHIP RESISTOR 150K 1/16W 5% T 1608
1
R4
C
05B-203-2Z
CHIP RESISTOR 20K 1/16W 5% T 1608
1
R2
C
05B-393-0Z
CHIP RESISTOR 39K 1/16W 5% T 1608
1
R5
C
05B-473-9Z
CHIP RESISTOR 47K 1/16W 5% T 1608
4
R7.8.12.14
C
05B-563-7Z
CHIP RESISTOR 56K 1/16W 5% T 1608
2
R6.11
C
05B-564-8Z
CHIP RESISTOR 560K 1/16W 5% T 1608
1
R3
C
097-103-6
THERMISTER CHIP 10K NTCCM20123NH103JCT
1
TH1
C
097-473-6
THERMISTOR CHIP NTCCM 16084LH 473JC 47K
1
TH2
C
130-A74-7Y
CHIP CERAMIC 0.1UF GRM39 Y5V104Z 25V P
1
C3
C
131-137-6Y
CERAMIC CHIP 100PF GRM39 U2J101J 50V
1
C2
C
131-564-8Y
CHIP CERAMIC 15PF GRM39 COG150J 50V P
1
C1
C
132-275-2
CHIP CERAMIC 22PF GRM39 U2J220J 50V P
1
C5
C
132-735-1Y
CHIP CERAMIC 270PF GRM39 COG271J 50V P
1
C6
C
134-012-1Y
CHIP CERAMIC 4PF GRM39 COG040C 50V P
1
C4
C
172-021-1
TRIMMER 20PF TZC03P200A110
1
CT1
C
202-082-6
TRANSISTOR KTA1504ST1(G)
1
Q2
C
202-112-0
TRANSISTOR KTC3875S(GR)
2
Q3.4
C
202-153-7
TRANSISTOR KTC3880SY
1
Q1
C
242-011-4
DIODE VARICAP MMBV109
1
D1
C
242-025-7
DIODE VARACTOR CHIP HVU300ATRU 30V
1
D2
C
263-374-3
CRYSTAL CA303HS 12.8MHZ 3PPM 14PF
1
X1
C
406-785-A
P.C.B TCXO 19X11X0.8T FR4
1
C
772-429
SHIELD CAN(TCXO) BSP T0.25 NI-PLATE
1
C
860-172
PIN TCXO PIN BRASS TIN PLATED
4
PIN
C
906-542
INSULATION PLATE FIBER T0.3
1
