Maxon SP200/210 Radio SP200/210

EXPLODED MECHANICAL DRAWINGS & PARTS LISTS

Issue 1.0

Page 8-14

03/01

8.4.4 V2

VCO

Category

Code & Part No.

Description

Qty

Location

C

05B-101-3Z

CHIP RESISTOR 100 1/16W 5% T 1608

1

R202

C

05B-103-5Z

CHIP RESISTOR 10K 1/16W 5% T 1608

1

R201

C

05B-104-6Z

CHIP RESISTOR 100K 1/16W 5% T 1608

1

R203

C

05B-201-0Z

CHIP RESISTOR 200 1/16W 5% T 1608

1

R209

C

05B-222-9Z

CHIP RESISTOR 2.2K 1/16W 5% T 1608

2

R206.207

C

05B-472-8Z

CHIP RESISTOR 4.7K 1/16W 5% T 1608

2

R205.208

C

05B-473-9Z

CHIP RESISTOR 47K 1/16W 5% T 1608

1

R204

C

060-104-9Z

CHIP RESISTOR 100K 1/10W 5% T 2012

1

RL202

C

130-A75-8Y

CHIP CERAMIC 0.001UF GRM39 X7R102K 50V P

4

C201.216.217
.220

C

131-091-7Y

CHIP CERAMIC 1PF GRM39 COG010C 50V P

2

C204.205

C

131-834-2Y

CHIP CERAMIC 18PF GRM39 COG180J 50V P

1

C215

C

132-024-2Y

CHIP CERAMIC 2PF GRM39 COG020C 50V P

1

C206

C

132-025-3Y

CHIP CERAMIC 20PF GRM39 COG200J 50V P

1

C203

C

132-260-8Y

CHIP CERAMIC 220PF GRM39 COG221J 50V P

1

C209

C

132-734-0Y

CHIP CERAMIC 27PF GRM39 COG270J 50V P

1

C212

C

133-348-0Y

CHIP CERAMIC 3.3PF GRM39 COG3R3C 50V P

1

C211

C

134-012-1Y

CHIP CERAMIC 4PF GRM39 COG040C 50V P

1

C218

C

134-756-0Y

CHIP CERAMIC 4.7PF GRM39 COG4R7C 50V P

1

C213

C

139-006-1Y

CHIP CERAMIC 9PF GRM426COG090D200V P

1

C208

C

200-067-3

TRANSISTOR 2SC5084-O

2

Q201.202

C

202-095-8Z

TRANSISTOR KRC104SND

1

Q203

C

242-025-7

DIODE VARACTOR CHIP HVU300ATRU 30V

1

D201

C

242-027-9

DIODE VARICAP CHIP 1SV217

1

D202

C

243-080-1

DIODE SI CHIP 1SS314

1

D203

C

311-070-4

COIL CHIP 0.18UH:NL252018T-R18J

1

L205

C

311-080-3

COIL CHIP 1.2UH:NL252018T-1R2J

2

L201.206

C

311-083-6

COIL CHIP 2.2UH:NL252018T-2R2J

1

L204

C

311-117-4

COIL CORE CHIP E558CN-100022

1

L203

C

406-764-C

P.C.B VCO 21X18X0.8 FR4 1/1

1

C

772-428

SHIELD CAN(VCO) NSP T0.2

1

8.4.5 V2 Front End

Category

Code & Part No.

Description

Qty

Location

C

05B-181-5Z

CHIP RESISTOR 180 1/16W 5% T 1608

1

R602

C

05B-229-6Z

CHIP RESISTOR 2.2 1/16W 5% T 1608

1

R604

C

05B-332-5Z

CHIP RESISTOR 3.3K 1/16W 5% T 1608

2

R601.605

C

05B-821-0Z

CHIP RESISTOR 820 1/16W 5% T 1608

1

R603

C

130-A75-8Y

CHIP CERAMIC 0.001UF GRM39 X7R102K 50V P

2

C616.620

C

131-093-9Y

CHIP CERAMIC 100PF GRM39 COG101J 50V P

2

C601.615

C

131-241-6Y

CHIP CERAMIC 120PF GRM39 COG121J 50V P

1

C609

C

131-405-8Y

CHIP CERAMIC 14PF GRM39 COG140J 50V P

1

C603

C

131-575-8Y

CHIP CERAMIC 150PF GRM39 COG151J 50V P

1

C611

C

132-025-3Y

CHIP CERAMIC 20PF GRM39 COG200J 50V P

1

C619

C

133-103-5Y

CHIP CERAMIC 30PF GRM39 COG300J 50V P

1

C606

C

133-349-1Y

CHIP CERAMIC 33PF GRM39 COG330J 50V P

1

C618

C

134-757-1Y

CHIP CERAMIC 47PF GRM39 COG470J 50V P

1

C612

C

136-209-3Y

CHIP CERAMIC 62PF GRM39 COG620J 50V P

1

C610

C

137-509-9Y

CHIP CERAMIC 75PF GRM39 COG750J 50V P

1

C608

C

203-181-7

TRANSISTOR MMBR951:SOT23

1

Q601

C

243-049-4Z

DIODE CHIP KDS226

1

D601

C

311-065-0

COIL CHIP 0.068UH:NL252018T-068J

1

L601

C

311-066-1

COIL CHIP 0.082UH:NL252018T-082J

1

L602

C

311-960-8

COIL SPRING 0.26X0.9X8T:L 26NH

4

L604.605.607
.608

C

406-765-B

P.C.B FRONT-END 27 X10 X0.8 FR4 1/1

1

C

772-427

SHIELD CAN(FRONT-ENDNSP T0.2

1
