Maxon SP200/210 Radio SP200/210
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
Issue 1.0
Page 8-10
03/01
Category
Code & Part No.
Description
Qty
Location
C
421-203-2
CONNECTOR DF15(6.2)-30DP-0.65V(51)
1
CON404
C
422-470-1
CONNECTOR WAFER 53048-0410 1.25W/B
1
CON401
C
436-046-5
SW TACT SKPT-1101VA
3
SW402.403.4
05
8.4.2 V2
RF
Category
Code & Part No.
Description
Qty
Location
C
05B-000-5Z
CHIP RESISTOR 0 1/16W 5% T 1608
5
R124.LK3.D9
03.C10.Q17
C
05B-100-2Z
CHIP RESISTOR 10 1/16W 5% T 1608
2
R79.908
C
05B-101-3Z
CHIP RESISTOR 100 1/16W 5% T 1608
7
R11.15.66.88.
97.130.26
C
05B-102-4Z
CHIP RESISTOR 1K 1/16W 5% T 1608
4
R54.71.86.94
C
05B-103-5Z
CHIP RESISTOR 10K 1/16W 5% T 1608
8
R1.53.82.98.1
03.104.106.1
11
C
05B-104-6Z
CHIP RESISTOR 100K 1/16W 5% T 1608
1
R2
C
05B-105-7Z
CHIP RESISTOR 1M 1/16W 5% T 1608
1
R50
C
05B-121-1Z
CHIP RESISTOR 120 1/16W 5% T 1608
1
R21
C
05B-122-2Z
CHIP RESISTOR 1.2K 1/16W 5% T 1608
2
R37.55
C
05B-123-3Z
CHIP RESISTOR 12K 1/16W 5% T 1608
1
R17
C
05B-151-8Z
CHIP RESISTOR 150 1/16W 5% T 1608
1
R63
C
05B-152-9Z
CHIP RESISTOR 1.5K 1/16W 5% T 1608
1
R96
C
05B-180-4Z
CHIP RESISTOR 18 1/16W 5% T 1608
2
R25.34
C
05B-182-6Z
CHIP RESISTOR 1.8K 1/16W 5% T 1608
4
R4.5.7.22
C
05B-183-7Z
CHIP RESISTOR 18K 1/16W 5% T 1608
2
R83.84
C
05B-202-1Z
CHIP RESISTOR 2K 1/16W 5% T 1608
1
R6
C
05B-220-7Z
CHIP RESISTOR 22 1/16W 5% T 1608
5
R23.24.41.64.
89
C
05B-222-9Z
CHIP RESISTOR 2.2K 1/16W 5% T 1608
5
R3.18.46.901.
902
C
05B-223-0Z
CHIP RESISTOR 22K 1/16W 5% T 1608
8
R45.67.68.76.
77.102.105.1
12
C
05B-224-1Z
CHIP RESISTOR 220K 1/16W 5% T 1608
1
R72
C
05B-271-3Z
CHIP RESISTOR 270 1/16W 5% T 1608
2
R56.110
C
05B-272-4Z
CHIP RESISTOR 2.7K 1/16W 5% T 1608
7
R13.14.78.81.
92.150.151
C
05B-273-5Z
CHIP RESISTOR 27K 1/16W 5% T 1608
2
R905.907
C
05B-301-7Z
CHIP RESISTOR 300 1/16W 5% T 1608
4
R29.30.31.32
C
05B-332-5Z
CHIP RESISTOR 3.3K 1/16W 5% T 1608
3
R12.52.95
C
05B-390-7Z
CHIP RESISTOR 39 1/16W 5% T 1608
1
R59
C
05B-391-8Z
CHIP RESISTOR 390 1/16W 5% T 1608
1
R10
C
05B-393-0Z
CHIP RESISTOR 39K 1/16W 5% T 1608
1
R85
C
05B-471-7Z
CHIP RESISTOR 470 1/16W 5% T 1608
2
R91.909
C
05B-472-8Z
CHIP RESISTOR 4.7K 1/16W 5% T 1608
2
R27.903
C
05B-473-9Z
CHIP RESISTOR 47K 1/16W 5% T 1608
2
R75.115
C
05B-474-0Z
CHIP RESISTOR 470K 1/16W 5% T 1608
4
R58.69.70.87
C
05B-475-1Z
CHIP RESISTOR 4.7M 1/16W 5% T 1608
1
R135
C
05B-510-9Z
CHIP RESISTOR 51 1/16W 5% T 1608
1
R65
C
05B-512-1Z
CHIP RESISTOR 5.1K 1/16W 5% T 1608
1
R20
C
05B-513-2
CHIP RESISTOR 51K 1/16W 5% T 1608
1
R19
C
05B-560-4Z
CHIP RESISTOR 56 1/16W 5% T 1608
1
R28
C
05B-562-6Z
CHIP RESISTOR 5.6K 1/16W 5% T 1608
1
R9
C
05B-752-1Z
CHIP RESISTOR 7.5K 1/16W 5% T 1608
2
R904.906
C
05B-822-1Z
CHIP RESISTOR 8.2K 1/16W 5% T 1608
1
R35
C
05B-911-8Z
CHIP RESISTOR 910 1/16W 5% 1608
2
R8.16
