SP200/210 Maxon SP200/210 Radio
Issue 1.0
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
03/01
Page 8-7
No.
Part No.
Part Name
Description
Qty
45
719-656
Cover Back
ALDC
1
46
421-197-0
Connector ANT
SMA-P(M) SW-2449
1
47
959-046-B
Label Name
Polyester 39.5 x 20.5
1
48
95A-177-A
Label FCC No.
Polyester 39.5 x 14.5
1
49
95A-670
Label Battery
Yupo Paper 25.5 x 49.5
1
50
719-657
Cover Battery
Lexan 141-70456
1
51
752-958
Terminal
BSP T1.2 Gold Plate
2
52
906-858
Double Sided Tape
32 x 17 x T0.4 TESA 4976
1
53
752-808
Contact Plate
18 x T0.15 Ni-Plate (DPB-1190A)
5
54
753-061
Spacer (For Battery)
ABS94HB- L401-9001
55
406-766-A
PCB Battery
38.2 x 87.6 x 0.5 M1 FLEX 1/0
1
56
906-857
Double Sided Tape
34 x 10 x T0.4 TESA 4976
1
57
753-037
Terminal
BSBM Gold Plate
4
58
719-659
Battery Pack (1350mAH)
Lexan 141-70456
1
59
732-975
Holder
PC Lexan 141-70456
1
60
611-388
(+) Machine Screw (PH)
M2.6 x 6 (+) PH
1
61
826-395
Knob Latch (1350mAH)
Lexan 141-70456
1
62
881-656
Spring (For Latch)
SUS 304 WPA Dia. 0.3
1
63
826-396
Latch
SUS T1.0
1
64
853-170
Insert (Holder)
BSBM M2.6
1
65
612-306
(+) Machine Screw
(BH) M2 x 5 Zn-Plate
4
68
895-686
Gasket
1
70
895-452
Gasket Ring
Silicone Rubber Black
4
73
895-660
Cushion
15 x 9 x 1.0T EVA Sponge
1
