SP200/210 Maxon SP200/210 Radio

Issue 1.0 EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
03/01

Page 8-9

Category

Code & Part No.

Description

Qty

Location

C

130-A75-8Y

CHIP CERAMIC 0.001UF GRM39 X7R102K 50V P

2

C415.445

C

130-A99-0Y

CHIP CERAMIC 0.012UF GRM39 X7R123K 25V P

1

C436

C

130-249-9

CHIP CERAMIC 0.0022UF GRM39 X7R222J 50V P

1

C418

C

130-261-9Y

CHIP CERAMIC 0.022UF GRM39 X7R223K 50V P

1

C421

C

130-340-7Y

CHIP CERAMIC 0.0033UF GRM39 X7R332K 50V P

1

C432

C

130-432-7Y

CHIP CERAMIC 0.0047UF GRM39 X7R472K 50V P

2

C488.489

C

130-529-2

CHIP CERAMIC 0.056UF GRM39 X7R563K 16V

1

C444

C

130-624-4

CHIP CERAMIC 0.68UF GRM40 Y5V684Z 16V P

1

C425

C

131-089-7Y

CHIP CERAMIC 1UF GRM40 Y5V105Z 16V P

3

C433.434.435

C

131-089-9Y

CHIP CERAMIC 1UF GRM426Y5V105Z 16V P

1

C416

C

131-100-6Y

CHIP CERAMIC 0.1UF GRM39 X7R104K 50V P

5

C403.414.427
.487.404

C

131-564-8Y

CHIP CERAMIC 15PF GRM39 COG150J 50V P

2

C428.429

C

132-260-8Y

CHIP CERAMIC 220PF GRM39 COG221J 50V P

5

C438.439.440
.441.493

C

134-770-2Y

CHIP CERAMIC 470PF GRM39 X7R471K 50V P

9

C405.407.410
.411.412.413.
419 437 447

C

136-840-2Y

CHIP CERAMIC 680PF GRM39 X7R681K 50V P

1

C424

C

141-052-5Z

CHIP TANTALUM 100UF 293D107X0006E2T6V

1

C442

C

141-059-2

CHIP TANTALUM 10UF 293D106X06R3A2T6.3V

4

C406.420.430
.454

C

144-720-0Z

CHIP TANTALUM 4.7UF 293D475X0020C2T20V

1

C443

C

144-722-2Z

CHIP TANTALUM 4.7UF 293D475X0010A2T10V

5

C417.446.450
.491.492

C

202-085-9Z

TRANSISTOR KRC101SNA

1

Q402

C

202-092-5

BRT KRA110SPK

1

Q401

C

202-095-8Z

TRANSISTOR KRC104SND

6

Q404.406.40
8.414.415.41
6

C

202-106-5

TRANSISTOR KTA1504SY

1

Q405

C

218-039-1Z

TRANSISTOR KRA101S

1

Q403

C

221-196-7

I.C EEPROM X25330SI (SOIC8PIN)

1

IC404

C

221-203-0

I.C AUDIO AMP TDA7233D (SO-8)

1

IC402

C

221-204-1

I.C OTP HD6473837UX

1

IC403

C

221-492-4

I.C ASIC MSIMXA

1

IC406

C

222-018-5A

I.C KIA324F-EL

1

IC408

C

223-224-9

I.C MC14066BDR2:SO14

1

IC401

C

231-064-4

I.C OP AMP LM358MX

1

IC407

C

243-051-5

DIODE SI CHIP KDS184S

1

D404

C

243-052-6

DIODE SI CHIP KDS193

1

D403

C

243-063-6

DIODE SWITCHING KDS181S A3

2

D401.402

C

262-775-7

CRYSTAL CHIP 3.579545M 50PM 12P

1

X401

C

310-659-2

COIL CHIP 10UH:LER015T100K

1

L401

C

4A6-090-E

P.C.B ASS'Y 125.1X113 X1.0 FR4 2/S

1

C

406-767-B

P.C.B LCD 20.7 X15 X1.0 FR4 2/S

1

C

416-097-E

P.C.B DIGITAL 101.1X55.5 X1.0 FR4 2/S

1

C

420-771-3

JACK MINIATURE HSJ-0861-01-410

1

J401
