Maxon SP200/210 Radio SP200/210
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
Issue 1.0
Page 8-4
03/01
No.
Part No.
Part Name
Description
Qty
1
719-665-A
Upper Cover
Lexan 141-70456
1
2
895-546
Dust Cap
Silicone Rubber
1
3
853-196
Insert (U/Cover)
BSBM M2x3.5x10.3H
2
4
895-545
Key Pad
Silicone Rubber
1
5
853-197
Insert (U/Cover)
BSBM M2x3.5x14H
2
6
895-557
Gasket
Silicone Rubber
1
7
795-878
Overlay
Lexan T0.25
1
8
723-955
Bracket
SUS T0.4
1
9
895-547
Option Key
Silicone Rubber
1
10
895-544
PTT Pad
Silicone Rubber
1
11
895-550
Lens LED
Silicone Rubber
1
12
826-393
Knob Volume
Lexan 141-70456
1
13
906-923
Double Sided Tape
3M 9448HK T0.16
1
14
814-279
Lens LCD
Acrylic
1
15
906-706
Felt (Spk)
Dia. 32.5mm Felt T0.3mm
1
16
895-490
Gasket
Dia. 39.5 x 0.33 x T1.0 ENA
Sponge
1
17
420-125-1
Speaker
4 ohm 1.0W 40mm G-4404
1
18
850-924
Bushing Mic.
Dia. 7.5mm x 5.5H PVC
1
19
420-206-0
Mic. Condenser
WM-063-AT 6 DIA.
1
20
508-751-A
Dome Sw.
1
21
416-097-A
PCB Digital
101.1 x 55.5 x 1.0 FR4 2/S
1
22
420-771-3
Miniature Jack
HSJ-0861-01-410
1
23
252-209-0
LCD
TTR 1866 DPFDPW
1
24
895-589
Back Lighter
13 x 2.6 x T3.2 Silicone Rubber
76
Table 8-1 - Parts List for Exploded Mechanical Drawing 1
