SP200/210 Maxon SP200/210 Radio
Issue 1.0
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
03/01
Page 8-21
8.5.4 VCO
05B-101-3Z
CHIP RESISTOR 100 1/16W 5% T 1608
1
R202
05B-103-5Z
CHIP RESISTOR 10K 1/16W 5% T 1608
1
R201
05B-104-6Z
CHIP RESISTOR 100K 1/16W 5% T 1608
1
R203
05B-183-7Z
CHIP RESISTOR 18K 1/16W 5% T 1608
1
R205
05B-221-8Z
CHIP RESISTOR 220 1/16W 5% T 1608
1
R209
05B-222-9Z
CHIP RESISTOR 2.2K 1/16W 5% T 1608
2
R206.207
05B-472-8Z
CHIP RESISTOR 4.7K 1/16W 5% T 1608
1
R208
05B-473-9Z
CHIP RESISTOR 47K 1/16W 5% T 1608
1
R204
130-A75-8Y
CHIP CERAMIC 0.001UF GRM39 X7R102K 50V P
1
C214
130-515-9Y
CHIP CERAMIC 0.5PF GRM39 COG0R5C 50V P
1
C206
130-704-3Y
CHIP CERAMIC 0.75PF GRM39 COG0R75C50V P
1
C204
131-092-8Y
CHIP CERAMIC 10PF RM39 COG100D 50V P
2
C203.212
131-563-7Y
CHIP CERAMIC 1.5PF GRM39 COG1R5C 50V P
1
C205
132-260-8Y
CHIP CERAMIC 220PF GRM39 COG221J 50V P
5
C201.209.216
.217.220
133-102-4Y
CHIP CERAMIC 3PF GRM39 COG030C 50V P
2
C213.218
134-012-1Y
CHIP CERAMIC 4PF GRM39 COG040C 50V P
2
C207.211
137-013-7Y
CHIP CERAMIC 7PF GRM39 COG070D 50V P
1
C215
176-012-3
CHIP TRIMMER 6PF TZC03Z060A110
1
C208
200-067-3
TRANSISTOR 2SC5084-O
2
Q201.202
202-095-8Z
TRANSISTOR KRC104SND
1
Q203
242-022-4
DIODE VARICAP CHIP 1SV229
2
D201.202
243-080-1
DIODE SI CHIP SS314
1
D203
311-051-7
COIL CHIP 0.033UH:NL252018T-033J
1
L205
311-067-2
COIL CHIP 0.1UH:NL252018T-R10J
2
L201.206
311-075-9
COIL CHIP 0.47UH:NL252018T-R47J
1
L202
311-078-2
COIL CHIP 0.82UH:NL252018T-R82J
1
L204
311-218-2
COIL CHIP VCOOSC1.2T E558AN-100040-P3
1
L203
406-764-C
P.C.B VCO 21X18X0.8 FR4 1/1
1
772-428
SHIELD CAN(VCO) NSP T0.2
1
05B-101-3Z
CHIP RESISTOR 100 1/16W 5% T 1608
1
R602
05B-563-7Z
CHIP RESISTOR 56K 1/16W 5% T 1608
1
R601
131-092-8Y
CHIP CERAMIC 10PF GRM39 COG100D 50V P
2
C602.611
131-240-5Y
CHIP CERAMIC 12PF GRM39 COG120J 50V P
1
C608
131-405-8Y
CHIP CERAMIC 14PF GRM39 COG140J 50V P
1
C610
131-604-1Y
CHIP CERAMIC 16PF GRM39 COG160J 50V P
1
C607
133-102-4Y
CHIP CERAMIC 3PF GRM39 COG030C 50V P
1
C606
133-348-0Y
CHIP CERAMIC 3.3PF GRM39 COG3R3C 50V P
3
C601.604.612
134-012-1Y
CHIP CERAMIC 4PF GRM39 COG040C 50V P
2
C605.614
134-770-2Y
CHIP CERAMIC 470PF GRM39 X7R471K 50V P
1
C603
135-631-5Y
CHIP CERAMIC 5.6PF GRM39 COG5R6C 50V P
1
C613
136-014-3Y
CHIP CERAMIC 6PF GRM39 COG060D 50V P
1
C609
200-067-3
TRANSISTOR 2SC5084-O
1
Q601
243-049-4
DIODE SI CHIP KDS226
1
D601
311-943-3
COIL SPRING 14NH 03095TL
2
L605.606
311-944-4
COIL SPRING 10.5NH 03094TR
5
L601.602.603
.604.607
406-787-A
P.C.B FRONT-END 27 X10 X0.8 FR4 1/1
1
772-427
SHIELD CAN(FRONT-ENDNSP T0.2
1
