Maxon SP200/210 Radio SP200/210

EXPLODED MECHANICAL DRAWINGS & PARTS LISTS

Issue 1.0

Page 8-12

03/01

Category

Code & Part No.

Description

Qty

Location

C

133-932-7Y

CHIP CERAMIC 39PF GRM40 COG390J 50V P

1

C73

C

134-301-1Y

CHIP CERAMIC 43PF GRM40 COG430J 50V P

1

C74

C

134-757-1Y

CHIP CERAMIC 47PF GRM39 COG470J 50V P

4

C105.117.163
.166

C

134-770-2Y

CHIP CERAMIC 470PF GRM39 X7R471K 50V P

21

C1.3-
4.7.8.20.33,4.
47.55.57,8.

C

61.62.66.78.8
0-82.84.103.

C

135-021-4Y

CHIP CERAMIC 5PF GRM39 COG050C 50V P

1

C46

C

135-103-5Y

CHIP CERAMIC 51PF GRM40 COG510J 50V P

1

C42

C

136-014-3Y

CHIP CERAMIC 6PF GRM39 COG060D 50V P

2

C16.56

C

138-011-0Y

CHIP CERAMIC 8PF GRM39 COG080D 50V P

1

C43

C

138-232-3Y

CHIP CERAMIC 82PF GRM39 COG820J 50V P

1

C93

C

141-046-0Z

CHIP TANTALUM 10UF 293D106X0010B2T10V

1

C65

C

141-059-2

CHIP TANTALUM 10UF 293D106X06R3A2T6.3V

2

C2.12

C

144-722-2Z

CHIP TANTALUM 4.7UF 293D475X0010A2T10V

5

C6.53.60.95.1
28

C

180-126-6

METAL POLY CAP 0.01UF 103K 63V BOX

2

C23.24

C

180-209-8

METAL POLY CAP 0.022UF 223K 63V BOX

1

C22

C

180-609-6

METAL POLY CAPACITOR0.68UF MKT370 63V

1

C21

C

200-003-5

TRANSISTOR BFR92A REEL

1

Q25

C

200-113-1

TRANSISTOR KTC4075

4

Q901.903.90
4.905

C

200-114-2

TRANSISTOR KTA2014

1

Q902

C

202-092-5

BRT KRA110SPK

4

Q2.4.9.32

C

202-095-8Z

TRANSISTOR KRC104SND

6

Q12.18.23.24
.28.260

C

202-106-5

TRANSISTOR KTA1504SY

2

Q7.8

C

202-113-1

TRANSISTOR KTC3875S(BL)

7

Q6.11.14.19.
21.26.27

C

202-116-4

TRANSISTOR KTA1663

1

Q22

C

203-181-7

TRANSISTOR MMBR951:SOT23

2

Q3.16

C

218-057-7Z

TRANSISTOR KRA104S

2

Q1.5

C

220-028-4

I.C REGULATOR TK11450MTR

1

IC1

C

221-324-6

RE POWER MODULE GNOK-M68776-E01

1

IC9

C

221-529-5

I.C PLL MC145193F (SO-20)

1

IC2

C

223-453-9

I.C FM IF MC3372D (SO-16) (MOB.80

1

IC5

C

231-064-4

I.C OP AMP LM358MX

1

IC3

C

243-012-0

DIODE MMBV3401LT1

2

D21.25

C

243-049-4Z

DIODE CHIP KDS226

3

D901.902.903

C

243-052-6

DIODE SI CHIP KDS193

2

D8.16

C

243-063-6

DIODE SWITCHING KDS181S A3

3

D13.14

C

243-087-8

DIODE CHIP UPP9401(T&R)50V 2.5W

2

D5.6

C

243-122-6

SCHOTTKY DIODE HSMS-2817 #L31

1

D9

C

245-040-5

DIODE REC CHIP SM4004 1A 400V SMD

1

D2

C

263-418-0

CRYSTAL NR2D 44.645M -30 15PM 32P 3R

1

X1

C

270-109-9

FILTER CERAMIC CFWM455F

1

CF1

C

270-314-7

DISCRIMINATOR CDBC455CX16-TC

1

X2

C

270-316-9

FILTER CERAMIC LTWM455HT

1

CF2

C

271-165-4

CRYSTAL FILTER 45Y15BN 45.1MHZ

1

XF1

C

280-110-2

FUSE 60 V 4 A 25NM-040-L REEL:SM

1

FUSE1

C

300-223-8

TRANSFORMERS CHIP 617PT-1019

2

T1.2

C

310-659-2

COIL CHIP 10UH:LER015T100K

1

L19

C

310-861-7

COIL CHIP 47NH:LL2012-F47NM

2

L1.2

C

311-067-2

COIL CHIP 0.1UH:NL252018T-R10J

2

L3.4
