Maxon SP200/210 Radio SP200/210
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
Issue 1.0
Page 8-18
03/01
Category
Code & Part No.
Description
Qty
Location
05B-911-8Z
CHIP RESISTOR 910 1/16W 5% 1608
2
R8.16
05C-104-6Z
CHIP RESISTOR 100K 1/16W 1% T 1608
2
R57.99
05C-683-2Z
CHIP RESISTOR 68K 1/16W 1% T 1608
2
R61.62
06F-108-3
CHIP RESISTOR 0.1 1W 1% 1218
1
R109
060-153-3Z
CHIP RESISTOR 15K 1/10W 5% T 2012
1
R116
060-243-1Z
CHIP RESISTOR 24K 1/10W 5% T 2012
1
R74
075-102-5
RES.CHIP TRIMMER K RH03E1C13X
2
RV2.4
075-103-6
RES.CHIP TRIMMER 10K RH03E1C14X
2
RV1.3
098-333-8
THERMISTOR CHIP 33K:NTCCS32163SH333KC
1
TH1
101-058-9
ELECT CAPACITOR 10UF 16V 20% 3X5
1
C129
130-A17-6Y
CHIP CERAMIC 0.001UF GRM40 X7R102K 50V P
1
C68
130-A48-4Y
CHIP CERAMIC 0.0015UF GRM39 X7R152K 50V P
1
C108
130-A60-4Y
CHIP CERAMIC 0.1UF GRM40 X7R104K 25V P
4
C79.102.111.
113
130-A73-6Y
CHIP CERAMIC 0.01UF GRM39 X7R103K 25V
17
C13.27.63.96.
106,14,6,23,6
,7.
131.901-
904.910.911
130-A74-7Y
CHIP CERAMIC 0.1UF GRM39 Y5V104Z 25V P
8
C11.15.17.26.
30.88.195.90
7
130-A75-8Y
CHIP CERAMIC 0.001UF GRM39 X7R102K 50V P
7
C18.98.104.1
22.145.164.1
94
130-341-8Y
CHIP CERAMIC 0.033UF GRM39 X7R333K 16V P
1
C112
130-443-7
CHIP CERAMIC 0.47UF GRM40 Y5V474Z 16V P
1
C59
131-039-1Y
CHIP CERAMIC 10PF GRM40 COG100C 50V P
1
C74
131-089-7Y
CHIP CERAMIC 1UF GRM40 Y5V105Z 16V P
7
C14.25.28.29.
70.94.192
131-092-8Y
CHIP CERAMIC 10PF GRM39 COG100D 50V P
2
C107.121
131-093-9Y
CHIP CERAMIC 100PF GRM39 COG101J 50V P
1
C52
131-100-6Y
CHIP CERAMIC 0.1UF GRM39 X7R104K 50V P
2
C48.124
131-240-5Y
CHIP CERAMIC 12PF GRM39 COG120J 50V
P
3
C10.83.90
131-405-8Y
CHIP CERAMIC 14PF GRM39 COG140J 50V
P
1
C92
131-511-0Y
CHIP CERAMIC 15PF GRM40 COG150J 50V
P
1
C38
131-834-2Y
CHIP CERAMIC 18PF GRM39 COG180J 50V
P
2
C905.906
132-259-8Y
CHIP CERAMIC 22PF GRM39 COG220J 50V
P
1
C87
132-260-8Y
CHIP CERAMIC 220PF GRM39 COG221J
50V P
28
C19.31.37.45.
47.54.115.14
6.
165.190.191.
303.304.307-
311. +
314.316.319.
321-323.325-
328
