SP200/210 Maxon SP200/210 Radio
Issue 1.0
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
03/01
Page 8-17
8.5.2 U2
RF
Category
Code & Part No.
Description
Qty
Location
05B-000-5Z
CHIP RESISTOR 0 1/16W 5% T 1608
3
R124.LK3.D9
03
05B-100-2Z
CHIP RESISTOR 10 1/16W 5% T 1608
2
R79.908
05B-101-3Z
CHIP RESISTOR 100 1/16W 5% T 1608
7
R11.15.28.66.
88.97.130
05B-102-4Z
CHIP RESISTOR 1K 1/16W 5% T 1608
4
R54.71.86.94
05B-103-5Z
CHIP RESISTOR 10K 1/16W 5% T 1608
8
R1.53.82.98.1
03.104.106.1
11
05B-104-6Z
CHIP RESISTOR 100K 1/16W 5% T 1608
1
R2
05B-105-7Z
CHIP RESISTOR 1M 1/16W 5% T 1608
1
R50
05B-122-2Z
CHIP RESISTOR 1.2K 1/16W 5% T 1608
2
R37.55
05B-123-3Z
CHIP RESISTOR 12K 1/16W 5% T 1608
3
R17.42.45
05B-152-9Z
CHIP RESISTOR 1.5K 1/16W 5% T 1608
2
R63.96
05B-180-4Z
CHIP RESISTOR 18 1/16W 5% T 1608
3
R25.34.26
05B-181-5Z
CHIP RESISTOR 180 1/16W 5% T 1608
1
R56
05B-182-6Z
CHIP RESISTOR 1.8K 1/16W 5% T 1608
4
R4.5.7.22
05B-183-7Z
CHIP RESISTOR 18K 1/16W 5% T 1608
2
R83.84
05B-202-1Z
CHIP RESISTOR 2K 1/16W 5% T 1608
1
R6
05B-220-7Z
CHIP RESISTOR 22 1/16W 5% T 1608
5
R23.24.41.64.
89
05B-222-9Z
CHIP RESISTOR 2.2K 1/16W 5% T 1608
5
R3.18.46.901.
902
05B-223-0Z
CHIP RESISTOR 22K 1/16W 5% T 1608
7
R67.68.76.77.
102.105.112
05B-224-1Z
CHIP RESISTOR 220K 1/16W 5% T 1608
1
R72
05B-271-3Z
CHIP RESISTOR 270 1/16W 5% T 1608
1
R110
05B-272-4Z
CHIP RESISTOR 2.7K 1/16W 5% T 1608
7
R13.14.78.81.
92.150.151
05B-273-5Z
CHIP RESISTOR 27K 1/16W 5% T 1608
2
R905.907
05B-301-7Z
CHIP RESISTOR 300 1/16W 5% T 1608
4
R29.30.31.32
05B-332-5Z
CHIP RESISTOR 3.3K 1/16W 5% T 1608
2
R52.95
05B-390-7Z
CHIP RESISTOR 39 1/16W 5% T 1608
1
R59
05B-391-8Z
CHIP RESISTOR 390 1/16W 5% T 1608
1
R10
05B-393-0Z
CHIP RESISTOR 39K 1/16W 5% T 1608
1
R85
05B-471-7Z
CHIP RESISTOR 470 1/16W 5% T 1608
2
R91.909
05B-472-8Z
CHIP RESISTOR 4.7K 1/16W 5% T 1608
2
R27.903
05B-473-9Z
CHIP RESISTOR 47K 1/16W 5% T 1608
2
R75.100
05B-474-0Z
CHIP RESISTOR 470K 1/16W 5% T 1608
4
R58.69.70.87
05B-475-1Z
CHIP RESISTOR 4.7M 1/16W 5% T 1608
1
R135
05B-510-9Z
CHIP RESISTOR 51 1/16W 5% T 1608
1
R65
05B-512-1Z
CHIP RESISTOR 5.1K 1/16W 5% T 1608
1
R20
05B-513-2
CHIP RESISTOR 51K 1/16W 5% T 1608
1
R19
05B-562-6Z
CHIP RESISTOR 5.6K 1/16W 5% T 1608
3
R9.12.35
05B-682-1Z
CHIP RESISTOR 6.8K 1/16W 5% T 1608
1
R33
05B-752-1Z
CHIP RESISTOR 7.5K 1/16W 5% T 1608
2
R904.906
