SP200/210 Maxon SP200/210 Radio
Issue 1.0
EXPLODED MECHANICAL DRAWINGS & PARTS LISTS
03/01
Page 8-15
8.5 SL100 UHF Parts List
8.5.1 U2 Control Circuit
Category
Code & Part No.
Description
Qty
Location
C
05B-000-5Z
CHIP RESISTOR 0 1/16W 5% T 1608
11
RLK4.7.8.11.
15.22.26.
LK29.30.33.3
4
05B-100-2Z
CHIP RESISTOR 10 1/16W 5% T 1608
1
R466
05B-102-4Z
CHIP RESISTOR 1K 1/16W 5% T 1608
1
R490
05B-103-5Z
CHIP RESISTOR 10K 1/16W 5% T 1608
4
R403.413.430
.440
05B-104-6Z
CHIP RESISTOR 100K 1/16W 5% T 1608
11
R409.420.454
.455.456.457.
458.
459.460.461.
472
05B-105-7Z
CHIP RESISTOR 1M 1/16W 5% T 1608
2
R408.445
05B-124-4Z
CHIP RESISTOR 120K 1/16W 5% T 1608
5
R405.428.436
.441.486
05B-152-9Z
CHIP RESISTOR 1.5K 1/16W 5% T 1608
1
R416
05B-154-1Z
CHIP RESISTOR 150K 1/16W 5% T 1608
1
R(LK18)
05B-202-1Z
CHIP RESISTOR 2K 1/16W 5% T 1608
1
R435
05B-203-2Z
CHIP RESISTOR 20K 1/16W 5% T 1608
3
R422.491.492
05B-204-3Z
CHIP RESISTOR 200K 1/16W 5% T 1608
2
R423.438
05B-220-7Z
CHIP RESISTOR 22 1/16W 5% T 1608
2
R477.482
05B-222-9Z
CHIP RESISTOR 2.2K 1/16W 5% T 1608
2
R424.483
05B-223-0Z
CHIP RESISTOR 22K 1/16W 5% T 1608
3
R412.470.RL
K27
05B-224-1Z
CHIP RESISTOR 220K 1/16W 5% T 1608
2
R404.464
05B-273-5Z
CHIP RESISTOR 27K 1/16W 5% T 1608
3
R425.427.429
05B-331-4Z
CHIP RESISTOR 330 1/16W 5% T 1608
1
R484
05B-334-7Z
CHIP RESISTOR 330K 1/16W 5% T 1608
2
R471.488
05B-472-8Z
CHIP RESISTOR 4.7K 1/16W 5% T 1608
3
R401.443.444
05B-473-9Z
CHIP RESISTOR 47K 1/16W 5% T 1608
13
R407.410.411
.415.419.432.
433.
450.451.467.
473.474.475
05B-513-2
CHIP RESISTOR 51K 1/16W 5% T 1608
3
R418.421.489
05B-561-5Z
CHIP RESISTOR 560 1/16W 5% T 1608
1
R402
05B-682-1Z
CHIP RESISTOR 6.8K 1/16W 5% T 1608
1
R406
05B-683-2Z
CHIP RESISTOR 68K 1/16W 5% T 1608
1
R426
05B-752-1Z
CHIP RESISTOR 7.5K 1/16W 5% T 1608
1
R487
05B-823-2Z
CHIP RESISTOR 82K 1/16W 5% T 1608
1
R493
130-A01-7Y
CHIP CERAMIC 0.015UF GRM39 X7R153K 25V P
1
C494
130-A49-5Y
CHIP CERAMIC 0.0018UF GRM39 X7R182K 50V P
1
C495
130-A73-6Y
CHIP CERAMIC 0.01UF GRM39 X7R103K 25V
1
C402
130-A74-7Y
CHIP CERAMIC 0.1UF GRM39 Y5V104Z 25V P
10
C401.408.422
.423.431.451.
452, 453,
486, 490
130-A75-8Y
CHIP CERAMIC 0.001UF GRM39 X7R102K 50V P
2
C415.445
130-A99-0Y
CHIP CERAMIC 0.012UF GRM39 X7R123K 25V P
1
C436
130-249-9
CHIP CERAMIC 0.0022UF GRM39 X7R222J 50V P
1
C418
130-261-9Y
CHIP CERAMIC 0.022UF GRM39 X7R223K 50V P
1
C421
