SCSI Description
Maxtor Atlas 10K III 5-21
5VCPFCTF +PSWKT[ &CVC 2CIG
The Standard Inquiry Data Page is returned by the drive in response to the INQUIRY
command if EVPD = 0. The data format is described inTable 5-24 and the fields are
described in Table 5-25.
Table 5-24 Standard Inquiry Data Page-Data Format
Table 5-25 Standard Inquir Data Page-Field Descriptions
$KV
$[VG
0 Peripheral Qualifier = 0
Peripheral Device Type = 0
(Direct Access Device)
1
RMB =
0
Device Type Modifier = 0
2 ISO Version = 0 ECMA Version = 0
ANSI Version = 3
(SCSI-3)
3
AERC
= 0
TrmTsk
= 0
Norm
ACA
= 0
Rsv’d Response Data Format = 2
4 Additional Length = 5Bh
5 Reserved
6 Rsv’d Rsv’d
Port
= 0
MultiP
= 0
Mch-
ngr
= 0
ACKQ-
REQQ
= 0
Addr32
Addr16
7
RelAdr
= 0
Wbus3
2
= 0
Wbus1
6
Sync
= 1
Linked
= 1
Trans-
Dis
= 1
Cm-
dQue
= 1
SftRe
= 0
8 - 15 Vendor Identification “MAXTOR”
16 - 31 Product Identification
32 - 35 Product Revision Level
36 - 47 Drive Serial Number
48 - 51 Reserved
52 - 53 SCSI Hardware Revision Number
54 Disk Controller Hardware Revision Number
55 Electronics Pass Number
56 Reserved Clocking QAS IUS
57 - 95 Reserved
(KGNF 0COG 8CNWG &GUETKRVKQP
Peripheral Qualifier 0 Non-zero if initiator selects an invalid logical unit.
Peripheral Device 0 0 indicates that this is a Direct Access Device.
ANSI Version 3 ANSI SCSI Level 3 (SCSI-3) is supported.
AERC 0 Asynchronous Event Reporting is not supported.
NormACA 0 Does not support setting NACA in CDB Control word.
Port 0 Only used when MultiP = 1.
MultiP 0 This field set to 1 if it is a multiport device.
Mchngr 0 Not embedded in or attached to a medium changer
