Installation
3-6 Maxtor Atlas 10K III
*#4&9#4' 126+105
%QPHKIWTCVKQP ,WORGTU CPF %QPPGEVKQPU
This section includes setup and configuration information for Maxtor Atlas 10K III
drives. These disk drives include
• The 16-bit multimode Ultra160 SCSI, wide version with 68-pin SCSI
connector,
• The 16-bit multimode Ultra160 SCSI, version with SCA-2 80-pin
connector.
• The 16-bit multimode Ultra320 SCSI, wide version with 68-pin SCSI
connector,
• The 16-bit multimode Ultra320 SCSI, version with SCA-2 80-pin
connector.
Specific individual settings for each drive type are described in Sections 3.5.1
through 3.5.4.
,WORGT 1RVKQPU QP VJG 2KP 9KFG 2%$
This section describes how to configure the jumpers on Maxtor Atlas 10K III disks
with 68-pin SCSI interface connectors. The following features are jumper-
selectable:
• A0, A1, A2, A3 – SCSI Bus Device Identification
• FO – Fault Out (Remote LED)
• DS – Delay Spin
• SE – Force SE (Single-Ended, Disable LVD)
• BO – Busy Out (Remote LED)
• WP – Write Protect
• SS – Stagger Spin
• NW – No Wide (Enable Narrow Mode)
• TERMPWR – Termination Power
Note: The disk drive does not support on-board SCSI termination.
%#76+10 Before you begin, review the Safety, ESD, and Handling precau-
tions described at the beginning of this manual to avoid personal in-
jury or damage to equipment.
