Maxtor Atlas 10K III I-1
+0&':
0WOGTKEU
4-pin DC power connector 3-21
512-byte sectors available 4-3
abbreviations 1-2
acoustics 4-7
Active Notch 5-59
actuator 4-6
Adapter, 50-pin to 68-pin 2-4
Additional Sense Codes 5-135, 5-139
Additional Sense Length 5-136
air temperature 3-25
Allocation Length 5-10, 5-38, 5-122, 5-
131, 5-132, 5-134
altitude2 4-8
ASCII Implemented Operating Definition
5-26
ASCII Implemented Operating Definition
Page 5-26
audience definition 1-1
auto head-park method 4-2
average write 4-2
AWRE 5-14, 5-48, 5-54
Bit Pointer 5-153
Block Descriptor 5-10, 5-14, 5-44, 5-45,
5-74, 5-75, 5-76, 5-87
Block Length 5-45, 5-136
Buffer Empty Ratio 5-50
Buffer Full Ratio 5-50
Buffer ID 5-109, 5-173, 5-174
Buffer Offset 5-109, 5-173, 5-174
buffer size 4-2
Bus Inactivity Limit 5-50
bus interface connector 3-16, 3-17, 3-20
Byte Transfer Length 5-10, 5-117, 5-175
bytes per sector 4-1
Caching 5-53, 5-54, 5-77, 5-85, 5-171
Caching Page 5-53, 5-85, 5-171
CHANGE DEFINITION Command 5-
13
Changeable Pages 5-46
clearance 3-24
Clearing Sense Data 5-133
Command Queuing 5-22
component life 4-10
Connect Time Limit 5-50
connector 3-15, 3-16, 3-17, 3-20
contact start/stop cycles 4-2
Contingent Allegiance Condition 5-7
Control Mode 5-7, 5-56, 5-57
Control Mode Page 5-56, 5-57
cooling fan requirements 3-25
Correction Span 5-49, 5-52
Cylinder Number of Defect 5-18
Cylinder Skew Factor 5-79
data transfer rate 2-2, 4-4
Data transfer Rates 4-2
Defect Descriptors 5-10, 5-11, 5-120
Defect List Format 5-112, 5-113, 5-115,
5-116
Defect List Header 5-10, 5-11, 5-16, 5-
17, 5-112, 5-113, 5-115, 5-116, 5-
120
Defect List Length 5-16, 5-17, 5-113, 5-
116, 5-120
Defect Lists 5-14
