SCSI Description

5-164

Maxtor Atlas 10K III

6TCPUNCVG #FFTGUU 2CIG

Table 5-200 shows the Translate Address Page that can be supplied with a SEND
DIAGNOSTIC command to request that the Translate Address Page be returned after
the next RECEIVE DIAGNOSTIC RESULTS command.

Table 5-200

Translate Address Page-Data Format

$KV

$[VG

0

Page Code (40h)

1

Reserved

2 - 3

Page Length (0Ah)

4

Reserved

Supplied Format

000b (LBA)

5

Reserved

Translate Format

101b (Physical Sector)

6 - 9

Address to Translate

(LBA Format)

10 -

13

Reserved
