SCSI Description
5-78 Maxtor Atlas 10K III
(QTOCV &GXKEG 2CIG J
The Format Drive Page (Table 5-94) describes the drive's medium format.
The data fields are described in Table 5-95. Note that the page is savable but no
parameters are changeable.
Table 5-94 Format Device Page-(Page 3)
$KV
$[VG
0 PS Rsvd Page Code (03h)
1 Page Length (16h)
2 - 3 Tracks Per Zone
4 - 5 Alternate Sectors/Zone
6 - 7 Alternate Tracks/Zone
8 - 9 Alternate Tracks/Logical Unit
10 - 11 Sectors/Track
12 - 13 Data Bytes/Physical Sector
14 - 15 Interleave
16 - 17 Track Skew Factor
18 - 19 Cylinder Skew Factor
20 SSEC HSEC RMB SURF Reserved
21 - 23 Reserved
