J1 on the 68-pin SCSI PCB contains a 12-pin auxiliary connector. The pin
assignments for this connector are shown in Table 3-9.

6CDNG

J1 Auxiliary 12-Pin Connector

J1 Auxiliary Connector Pins

MATING CONNECTOR TYPE

AND PART NUMBER

(OR EQUIVALENT)

PIN

NUMBER

FUNCTION

1

SCSI Addr -

A0

12-pin connector:

Hirose Electric Co.

Dual-row crimp socket: A3B-12D-

2C

Crimp terminals: A3B-26305CC

(or equivalent)

2

XTFAULT

3

SCSI Addr -

A1

4

GND

5

SCSI Addr -

A2

6

GND

7

SCSI Addr -

A3

8

Busy Out

9

NC

10

GND

11

LED Pwr (+5

V)

12

NC
