SCSI Description
Maxtor Atlas 10K III 5-83
5CXGF 6TCKPKPI %QPHKIWTCVKQP 8CNWGU 5WDRCIG
The saved training configuration values subpage is used to report the SCSI device's
saved training configuration values. These vendor specific values are maintained by the
SCSI device when the retain training information option is enabled. The fields are
listed in Table 5-99; however the content of the fields is vendor specific. Only values
for the current I_T nexus are reported.
Table 5-99 Saved Training Configuration Subpage (02h)
$KV
$[VG
0 MSB
Reserved
3 LSB
4 MSB
DB(0) Value
7 LSB
64 MSB
DB(15) Value
67 LSB
68 MSB
P_ORCA Value
71 LSB
72 MSB
P1 Value
75 LSB
76 MSB
BSY Value
79 LSB
80 MSB
SEL Value
83 LSB
84 MSB
RST Value
87 LSB
88 MSB
REQ Value
91 LSB
92 MSB
ACK Value
95 LSB
96 MSB
ATN Value
99 LSB
100 MSB
C/D Value
103 LSB
104 MSB
I/O Value
107 LSB
108 MSB
MSG Value
111 LSB
112 MSB
Reserved
227 LSB
