Installation
3-18 Maxtor Atlas 10K III
(S) = Short pin
(L) = Long pin
2KP 5%# /CVKPI %QPPGEVQTU
The compatible 80-pin mating connectors are:
• Right-angle receptacle, AMP CHAMP, .050 Series I, part number 787535-1.
• Vertical receptacle, AMP CHAMP .050 Series I, part number 787311-2.
• Vertical receptacle, BERG part number 71780-001.
(S) –DB (2) 26 (S) +DB (2) 66
(S) –DB (1) 27 (S) +DB (1) 67
(S) –DB (0) 28 (S) +DB (0) 68
(S) –DB (P1) 29 (S) +DB (P1) 69
(S) –DB (15) 30 (S) +DB (15) 70
(S) –DB (14) 31 (S) +DB (14) 71
(S) –DB (13) 32 (S) +DB (13) 72
(S) –DB (12) 33 (S) +DB (12) 73
(S) 5V 34 (S) MATED 2 74
(S) 5V 35 (L) 5V GROUND 75
(L) 5V CHARGE 36 (L) 5V GROUND 76
(L) SPINDLE SYNC 37 (L) ACTIVE LED OUT 77
(L) RMT START 38 (L) DLYD_START 78
(L) SCSI ID (0) 39 (L) SCSI ID (1) 79
(L) SCSI ID (2) 40 (L) SCSI ID (3) 80
