-4-
Model g1033X (Mfg. since 4/12)
The information contained herein is deemed accurate as of 5/21/2012 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2 Model G1033X
0$&+,1('$7$
6+((7
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
02'(/*;+363,5$/&877(5+($'3/$1(5
Product Dimensions:
Weight.............................................................................................................................................................. 875 lbs.
Width (side-to-side) x Depth (front-to-back) x Height........................................................................... 39 x 56 x 41 in.
Footprint (Length x Width)............................................................................................................................ 28 x 22 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 909 lbs.
Length x Width x Height....................................................................................................................... 45 x 30 x 46 in.
Electrical:
Minimum Circuit Size........................................................................................................................................ 30 amp
Switch...................................................................................................... Magnetic with Thermal Overload Protection
Switch Voltage..................................................................................................................................................... 220V
Cord Length.......................................................................................................................................................... 10 ft.
Cord Gauge................................................................................................................................................... 10 gauge
Plug Included........................................................................................................................................................... No
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower................................................................................................................................................ 5 HP
Voltage....................................................................................................................................................... 220V
Prewired..................................................................................................................................................... 220V
Phase....................................................................................................................................................... Single
Amps............................................................................................................................................................ 30A
Speed................................................................................................................................................ 3450 RPM
Cycle......................................................................................................................................................... 60 Hz
Number of Speeds............................................................................................................................................ 1
Power Transfer ..................................................................................................................... Triple V-Belt Drive
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Operation Info
Max. Cut Width.......................................................................................................................................... 20 in.
Min. Stock Length....................................................................................................................................... 7 in.
Min. Stock Thickness................................................................................................................................ 1/4 in.
Max. Stock Thickness............................................................................................................................ 8-5/8 in.
No. of Cuts Per Inch............................................................................................................................... 83, 104
No. of Cuts Per Minute............................................................................................................................. 20000
Cutterhead Speed............................................................................................................................. 5000 RPM
Planing Feed Rate........................................................................................................................... 16, 20 FPM
Max. Cut Depth Planing Full Width......................................................................................................... 5/64 in.
Max. Cut Depth Planing 6 Inch Wide Board.................................................................................................. 1/8
Machine Data Sheet
23A
