Headstock parts list – Grizzly G1033X User Manual
Page 46
-44-
Model g1033X (Mfg. since 4/12)
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
P1033X001
ROUND KNOB 5/16-18
35
P1033X035
EXTENSION SPRING 8.5 X 14
2
P1033X002
V-BELT COVER
36
P1033X036
HANGER
3
PVM59
V-BELT M59 3L590
38
P1033X038
LEFT BACKING PLATE
4
P1033X004
STUD
40
PSS13M
SET SCREW M10-1.5 X 12
5
PB09M
HEX BOLT M8-1.25 X 20
41
PSS14M
SET SCREW M8-1.25 X 12
6
PWF08M
FENDER WASHER 8MM
42
P1033X042
HEAD CASTING
7
PFS02M
FLANGE SCREW M6-1 X 12
43
P1033X043
SHAFT 15.875 X 60
8
P1033X008
PULLEY GUARD
44
PN01M
HEX NUT M6-1
9
PN02
HEX NUT 5/16-18
45
PSS25M
SET SCREW M6-1 X 20
10
P1033X010
CUTTERHEAD PULLEY
46
PFH30M
FLAT HD SCR M5-.8 X 8
11
P1033X011
DUST HOOD ASSEMBLY
47
P1033X047
DEPTH LIMITER
12
PB02M
HEX BOLT M6-1 X 12
48
PB09M
HEX BOLT M8-1.25 X 20
13
PW03M
FLAT WASHER 6MM
49
P1033X049
SCALE ASSEMBLY
14
PSB26M
CAP SCREW M6-1 X 12
49-1
PS14M
PHLP HD SCR M6-1 X 12
15
P1033X015
UPPER COVER
49-2
P1033X049-2
INDICATOR
16
PW03M
FLAT WASHER 6MM
49-3
P1033X049-3
SCALE
17
PSB01M
CAP SCREW M6-1 X 16
49-4
PSB50M
CAP SCREW M5-.8 X 10
18
P1033X018
HANDWHEEL ASSEMBLY
50
P6206ZZ
BALL BEARING 6206ZZ
18-1
P1033X018-1
HANDWHEEL
51
PK09M
KEY 8 X 8 X 36
18-2
P1033X018-2
HANDLE M12-1.75
52A
P1033X052A
SPIRAL CUTTERHEAD ASSY V2.07.07
20
P1033X020
GASKET
52A-1 H9893
INSERTS 15 X 15 X 2.5-10 PK
21
P1033X021
CHIP DEFLECTOR
52A-2 PFH32
FLAT HEAD TORX 10-32 X 1/2
22
P1033X022
SPRING PLATE
52A-3 P1033X052A-3 SPIRAL CUTTERHEAD BODY V2.07.07
23
PSS11M
SET SCREW M6-1 X 16
53
P1033X053
COMPRESSION SPRING 19.7 X 12
24
P1033X024
SPRING PLATE
54
P1033X054
BUSHING BLOCK
25
P1033X025
OILER SCREW M22-1.5
55
P1033X055
PLATE
26
PW01M
FLAT WASHER 8MM
56
PLW04M
LOCK WASHER 8MM
27
P1033X027
BRACKET
57
P1033X057
PRESSURE BAR
28
P1033X028
SHAFT M22-.5 X 20
58
P1033X058
OUTFEED ROLLER
29
P1033X029
IDLER PULLEY
59
PK01M
KEY 5 X 5 X 22
30
P1033X030
SHAFT 19.05 X 21
60
P1033X060
SPROCKET
31
P1033X031
RIGHT BACKING PLATE
61
PW03M
FLAT WASHER 6MM
32
PRP07M
ROLL PIN 6 X 20
62
PB83M
HEX BOLT M6-1 X 16
33
P1033X033
CHAIN DRIVE COVER
63
P1033X063
BRACKET
34
PSB12M
CAP SCREW M8-1.25 X 40
Headstock Parts List
