Stand/motor parts list – Grizzly G1033X User Manual
Page 51
Model g1033X (Mfg. since 4/12)
-49-
Stand/Motor Parts List
REF PART #
DESCRIPTION
REF
PART #
DESCRIPTION
7
PFS02M
FLANGE SCREW M6-1 X 12
167
PN09M
HEX NUT M12-1.75
16
PW03M
FLAT WASHER 6MM
168
P1033X168
ADJUSTABLE BOLT 25.4 X 120
39
P1033X039
MAG SWITCH SDE MPE-30
169V2
P1033X169V2
MOTOR 5HP 220V 1-PH V2.04.10
39-1 P1033X039-1 CONTACTOR SDE MA-30 220V
169V2-1 P1033X169V2-1
CAPACITOR COVER
39-2 P1033X039-2 MAG SWITCH FRONT COVER
169V2-2 P1033X169V2-2
MOTOR FAN COVER
39-3 P1033X039-3 OL RELAY SDE RA-30 22-34
169V2-3 P1033X169V2-3
MOTOR FAN
39-4 P1033X039-4 MAG SWITCH BACK COVER
169V2-4 P1033X169V2-4
S CAPACITOR 250M 300V 1-3/4 X 3-1/2
41
PSS14M
SET SCREW M8-1.25 X 12
169V2-5 P1033X169V2-5
R CAPACITOR 450V 35M
73
PN09M
HEX NUT M12-1.75
169V2-6 P1033X169V2-6
CENTRIFUGAL SWITCH
92
P1033X092
FOOT
169V2-7 P1033X169V2-7
JUNCTION BOX
120
PFH06M
FLAT HD SCR M6-1 X 20
169V2-8 P1033X169V2-8
MOTOR LABEL
121
P1033X121
PANEL
170
P1033X170
BAR
122
P1033X122
CABINET STAND
182
P1033X229
NYLOCK HEX BOLT M8-1.25 X 20
123
P1033X123
FRONT COVER
202
PS38M
PHLP HD SCR M4-.7 X 10
124
PN06M
HEX NUT M5-.8
203
G8589
GRIZZLY NAMEPLATE-LARGE
125
P1033X125
STRAIN RELIEF
220
P1033X220
STRAIN RELIEF
126
P1033X126
START SWITCH
221
P1033X221
POWER CORD 10G 3W
127
P1033X127
STOP SWITCH
222
P1033X222
STRAIN RELIEF
128
P1033X128
POWER LIGHT
223
PTLW02M
EXT TOOTH WASHER 5MM
129
P1033X129
SWITCH PANEL
224
PS09M
PHLP HD SCR M5-.8 X 10
130
P1021X2145
SWITCH BOX
225
PS20M
PHLP HD SCR M5-.8 X 15
131
P1033X131
SWITCH ELBOW BRACKET
226
P1033X226
SWITCH PANEL
132
PS09M
PHLP HD SCR M5-.8 X 10
227
P1033X227
MOTOR CORD 10G 3W
133
PW06M
FLAT WASHER 12MM
228
P1033X228
SWITCH CORD 18G 4W
162
P1033X162
MOTOR BRACKET
229
P1033X229
NYLOCK HEX BOLT M8-1.25 X 20
163
P1033X163
COLLAR
230
PW01M
FLAT WASHER 8MM
164
PB15M
HEX BOLT M8-1.25 X 40
231
P1033X231
MOTOR PULLEY 28MM ID
165
PN03M
HEX NUT M8-1.25
232
P1033X232
MOTOR SHAFT KEY 8 X 7 X 55
166
PW01M
FLAT WASHER 8MM
