Grizzly G1033X - Manual (Page 47)

Model g1033X (Mfg. since 4/12)
-45-
REF PART # DESCRIPTION REF PART # DESCRIPTION
64 P1033X064 SHAFT 15.875 X 710 91-7 PW03M FLAT WASHER 6MM
65 P1033X065 CHIP BREAKER 93 P1033X093 OIL PLUG
66 P1033X066 SPROCKET 94 P1033X094 OIL SEAL 28 X 40 X 8
67 PR03M EXT RETAINING RING 12MM 95 P1033X095 GEAR BOX
68 PEC05M E-CLIP 15MM 95A P1033X095A GEAR BOX ASSY
69 P1033X069 SPACER 96 P1033X096 GASKET
70 P1033X070 ANTI-KICKBACK FINGER 97 P1033X097 DOUBLE GEAR 96T/92T
71 P1033X071 LOCK ROD 98 PFS14M FLANGE SCREW M6-1 X 16
72 P1033X072 SHAFT 19.95 X 680 99 P1033X099 SHAFT 20 X 106
73 PN09M HEX NUT M12-1.75 100 P4002429 COMPRESSION SPRING 5.9 X 9
74 P1033X074 INFEED ROLLER 101 PSTB003M STEEL BALL 6MM
75 P1033X075 CHAIN 102 P1033X102 OIL SEAL 25 X 47 X 6
76 PSB05M CAP SCREW M8-1.25 X 50 103 P6204ZZ BALL BEARING 6204ZZ
77 P6204ZZ BALL BEARING 6204ZZ 104 P1033X104 SHIFTER
78 P1033X078 GEAR 16T 105 P1033X105 SHIFTING SHAFT
79 PSB06M CAP SCREW M6-1 X 25 106 POR0012 O-RING 12 X 2.4
80 P6201 BALL BEARING 6201ZZ 116 PSS04M SET SCREW M6-1 X 12
81 P1033X081 GEAR 47T 117 P6201ZZ BALL BEARING 6201ZZ
82 P1033X082 GEAR 18T AND SHAFT 133 PW06M FLAT WASHER 12MM
83 PK10M KEY 5 X 5 X 12 159 PK05M KEY 4 X 4 X 10
84 P1033X084 GEAR CASE COVER 171 P1033X171 ROLLER STAND
85 P1033X085 PIN 8 X 20 172 P1033X172 ROLLER
86 P1033X086 GEAR 18T/22T 2-SPEED 173 P1033X173 ROLLER SHAFT
87 PK11M KEY 6 X 6 X 40 174 P1033X174 WORM GEAR BOX
88 PK06M KEY 5 X 5 X 10 175 PSB37M CAP SCREW M6-1 X 50
89 P1033X089 GEAR 71T 176 P1033X176 WORM
90 P1033X090 BALL KNOB 3/8-16 177 PR29M INT RETAINING RING 32MM
91 P1033X091 SPROCKET & CHAIN ASSY 178 P1033X178 COLLAR
91-1 P1033X091-1 CHAIN 179 PW03M FLAT WASHER 6MM
91-2 P1033X091-2 SPROCKET 180 PSB04M CAP SCREW M6-1 X 10
91-3 P1033X091-3 OUTER CHAIN TENSIONER 200 PSB04M CAP SCREW M6-1 X 10
91-4 P1033X091-4 SHAFT 19.05 X 21 201 P6202ZZ BALL BEARING 6202ZZ
91-5 P1033X091-5 BRACKET 233V3 P1033X233V3 T-HANDLE T-25 TORX DRIVER V2.06.11
91-6 PSB48M CAP SCREW M6-1 x 35
