SNVT_state_64
Data Length 4
Suggested Data Array Formats Packed_Bit, Uint16, Float
Data Item 1 state_64_word0
Measurement Units Values Range Invalid Value
Boolean Bit 0, 1 per bit ( 16
bits in word ) N/A
Data Item 2 state_64_word1
Measurement Units Values Range Invalid Value
Boolean Bit 0, 1 per bit ( 16
bits in word ) N/A
Data Item 3 state_64_word2
Measurement Units Values Range Invalid Value
Boolean Bit 0, 1 per bit ( 16
bits in word ) N/A
Data Item 4 state_64_word3
Measurement Units Values Range Invalid Value
Boolean Bit 0, 1 per bit ( 16
bits in word ) N/A
SNVT_str_asc
Data Length 31
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1 - 31 ascii00, ascii01, .. ascii30
Measurement Units Values Range Invalid Value
Character String N/A 0 .. 255 N/A
SNVT_str_int
Data Length 16
Suggested Data Array Formats Uint16, Float
Data Item 1 char_set
Measurement Units Values Range Invalid Value
Locale Code N/A 0 .. 255 N/A
Data Item 2 - 16 wide_char00, ..
wide_char14
Measurement Units Values Range Invalid Value
Wide-character string
with NULL terminator N/A 0 .. 65,535 N/A
SNVT_switch
Data Length 2
Suggested Data Array Formats Float
Data Item 1 Value
Measurement Units Values Range Invalid Value
Value Percentage of full scale 0 .. 100.0 N/A
Data Item 2 State
Measurement Units Values Range Invalid Value
State N/A 0 .. 1 -1
SNVT_telcom
Data Length 1
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
telcom_states_t N/A 0 .. 20 255 (0xFF)(TEL_NUL)
SNVT_temp
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Temperature Degrees Celsius -274.0 .. 6,279.5 N/A
