Data Item 16 Month
Measurement Units Values Range Invalid Value
Month month of year 0 ..12 N/A
Data Item 17 Day
Measurement Units Values Range Invalid Value
Day day of month 0 ..31 N/A
Data Item 18 Hour
Measurement Units Values Range Invalid Value
Hour Hour of day 0 ..23 N/A
Data Item 19 Minute
Measurement Units Values Range Invalid Value
Minute Minutes 0 ..59 N/A
Data Item 20 Second
Measurement Units Values Range Invalid Value
Second Seconds 0 ..59 N/A
Data Item 21 Millisecond
Measurement Units Values Range Invalid Value
Millisecond Milliseconds 0 ..999 N/A
Data Item 22-25 Alm_limit00, ..Alm_limit03
Measurement Units Values Range Invalid Value
Alarm limit array
element
specific to NVT 0 .. 255 N/A
SNVT_amp
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Electric current Amperes -3,276.8... 3,276.7 N/A
SNVT_amp_ac
Data Length 1
Suggested Data Array Formats Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Alternating electric
current
Amperes 0 .. 65,534 65,535 (0xFFFF)
SNVT_amp_f
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Electric current Amperes -3.40282E38 ..
3.40282E38
N/A
SNVT_amp_mil
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Electric current Milli-amperes -3,276.8.. 3,276.7 N/A
SNVT_angle
Data Length 1
Suggested Data Array Formats Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Phase/Rotation Radians 0 .. 65.535 N/A
SNVT_angle_deg
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Angular distance degrees -359.98 .. 360.00 Type: 655.34 Raw: 32,767
(0x7FFF)
SNVT_angle_f
Data Length 1
Suggested Data Array Formats Float
