Data Item 1
Measurement Units Values Range Invalid Value
Phase/Rotation Radians -3.40282E38 ..
3.40282E38
N/A
SNVT_angle_vel
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Angular velocity Radians/second -3,276.8 .. 3,276.7 N/A
SNVT_angle_vel_f
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Angular Velocity Radians/Second -3.40282E38 ..
3.40282E38
N/A
SNVT_area
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Area Square meters (m²) 0 .. 13.1068 Type: 13.107 Raw:
0xFFFF (65,535)
SNVT_btu_f
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Thermal Energy British Thermal Units 0 .. 3.40282E38 N/A
SNVT_btu_kilo
Data Length 1
Suggested Data Array Formats Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Thermal Energy Kilo-British Thermal
Units
0 .. 65,535 N/A
SNVT_btu_mega
Data Length 1
Suggested Data Array Formats Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Thermal Energy Mega-British Thermal
Units 0 .. 65,535 N/A
SNVT_char_ascii
Data Length 1
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Character 8-bit ASCII Character 0 .. 255 N/A
SNVT_chlr_status
Data Length 3
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1 chlr_run_mode
Measurement Units Values Range Invalid Value
Byte, Uint16, Float 8-bit ASCII Character 0 .. 255 N/A
Data Item 2 chlr_op_mode
Measurement Units Values Range Invalid Value
hvac_t N/A 0 .. 17 255 (0xFF)(HVAC_NUL)
Data Item 3 chlr_state
Measurement Units Values Range Invalid Value
N/A 0 .. 255 N/A
