FS-8700-21 LonWorks Manual

Page 21 of 72

FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com

Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]

7.2.6 Using Neuron ID to Address Devices (Client Drivers only)

It is possible to poll remote LonWorks devices using their Neuron ID's instead of the traditional Network Manager method. The Neuron ID is the 12 Digit Hex
identifier of the associated LonWorks Device. An example configuration follows.

Note that Neuron ID addressing is considered explicit addressing so the station address, domain ID and subnet ID must be set as described in Section 7.1.4

Neuron ID addressing is independent of domains, subnet, nodes and can therefore reach any device connected to the LonWorks network. The FieldServer
needs to be commissioned with a Network Management tool for the routers to know it's there, and then neuron based packets will be passed through the
router.

Bridge

System_Station_Address , Title
110

, D01:S01:Neuron ID Example:

On the Client side add a new field under Nodes as shown below:

Nodes

Node_Name , Node_ID , Protocol

, Neuron_ID

Lon_Srv_11

, 11

, Lonworks , F912AB440100

Create a Map Descriptor as Follows:

Map_Descriptors

Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Lon_Function , Function , Node_Name , SNVT_Index , SNVT_Type , Scan_Interval
1nviAmp1

, DA_001

, 0

, NMFETCHC

, RDBC

, Lon_Srv_11

, 000

, SNVT_amp , 0s
