FS-8700-21 LonWorks Manual Page 58 of 72
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
SNVT_nv_type
Data Length 15
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1-8
nv_type_pid0,
..nv_type_pid7
Measurement Units Values Range Invalid Value
Program ID N/A 0 .. 255 N/A
Data Item 9 nv_type_scope
Measurement Units Values Range Invalid Value
Scope N/A 0 .. 6 N/A
Data Item 10 nv_type_index
Measurement Units Values Range Invalid Value
Type index N/A 1 .. 65,535 0
Data Item 11 nv_type_cat
Measurement Units Values Range Invalid Value
nv_type_category_t N/A 1 .. 14 255 (0xFF)(NVT_CAT_NUL)
Data Item 12 nv_type_length
Measurement Units Values Range Invalid Value
Type length Bytes 1 .. 31 0
Data Item 13 nv_type_scale_a
Measurement Units Values Range Invalid Value
Scaling multiplier N/A -32,768 .. 32,766 32,767
Data Item 14 nv_type_scale_b
Measurement Units Values Range Invalid Value
Scaling exponent N/A -32,768 .. 32,766 32,767
Data Item 15 nv_type_scale_c
Measurement Units Values Range Invalid Value
Scaling offset N/A -32,768 .. 32,766 32,767
SNVT_obj_request
Data Length 2
Suggested Data Array Formats Uint16, Float
Data Item 1 obj_request_id
Measurement Units Values Range Invalid Value
obj_request_id File Byte Address 0 .. 2,147,483,647 N/A
Data Item 2 obj_request
Measurement Units Values Range Invalid Value
object_request_t N/A 0 .. 17 255 (0xFF)(RQ_NUL)
SNVT_obj_status
Data Length 2
Suggested Data Array Formats Uint32
Data Item 1 obj_status_id
Measurement Units Values Range Invalid Value
Functional Block ID N/A 0 .. 65,535 N/A
Data Item 2 obj_status_bits
Measurement Units Values Range Invalid Value
object_status_bits Bits 0 .. 4,294,967,295 N/A
SNVT_occupancy
Data Length 1
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Occup_t N/A 0 .. 3 255 (0xFF)(OC_NUL)
SNVT_override
Data Length 1
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
override_t N/A 0 .. 2 255 (0xFF)(OV_NUL)
