FS-8700-21 LonWorks Manual Page 22 of 72
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
7.3 Server Side Configuration
7.3.1 Server Side Connection Parameters
Section Title
Connections
Column Title Function
Legal Values
Adapter Adapter Name LonWorks
Protocol Specify protocol used LonWorks
Example
// Server Side Connections
Connections
Adapter , Protocol
LonWorks , LonWorks
7.3.2 Server Side Node Parameters
Section Title
Nodes
Column Title
Function Legal Values
Node_Name Provide name for Node Up to 32 alphanumeric characters
Protocol Specify protocol used LonWorks
Startup_Write Initiate a send on startup. Enabled, Disabled
Example
// Server Side Nodes
Nodes
Node_Name , Protocol
LON_1 , LonWorks
7.3.3 Server Side Map Descriptor Paramete rs
7.3.3.1 FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor Up to 16 alphanumeric characters.
Data_Array_Name
Name of Data Array where data is to be stored or
fetched from in the FieldServer One of the Data Array names defined in
Section 5
Data_Array_Offset Starting location in Data Array
0 to (Data_Array_Length-1) as specified
in Section 5
Lon_Function Detailed Function of Client Map Descriptor See Section 7.1.2 for a list of valid
entries.
Function Function of Client Map Descriptor
