SNVT_setting
Data Length 3
Suggested Data Array Formats Float
Data Item 1 setting_function
Measurement Units Values Range Invalid Value
setting_t N/A 0 .. 5 255 (0xFF)(SET_NUL)
Data Item 2 setting_setting
Measurement Units Values Range Invalid Value
Scene Setting Level Percent of Full Level 0 .. 100.0 N/A
Data Item 3 setting_rotation
Measurement Units Values Range Invalid Value
Rotation Angle Degrees -359.98 .. 360.00 Raw: (0x7FFF) 32,767
Type: 655.34
SNVT_smo_obscur
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Smoke Obscuration Percent Obscuration 0.000 .. 5.000 N/A
SNVT_sound_db
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Sound Level Decibels -327.68 .. 327.67 N/A
SNVT_sound_db_f
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Sound Level Decibels from Sound
Pressure Level -3.40282E38 ..
3.40282E38
N/A
SNVT_speed
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Linear Velocity Meters per Second 0 .. 6,553.5 N/A
SNVT_speed_f
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Speed Meters per Second -3.40282E38 ..
3.40282E38
N/A
SNVT_speed_mil
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Linear Velocity Millimeters per Second 0 .. 65,535 N/A
SNVT_state
Data Length 1
Suggested Data Array Formats Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
16 state bits Bits 0 .. 65,535 N/A
