FS-8700-21 LonWorks Manual Page 55 of 72
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
SNVT_hvac_mode
Data Length 1
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Hvac_t N/A 0 .. 17 255 (0xFF)(HVAC_NUL)
SNVT_hvac_overid
Data Length 3
Suggested Data Array Formats Float
Data Item 1 hvac_ord_state
Measurement Units Values Range Invalid Value
hvac_overid_t N/A 0 .. 48 255 (0xFF)(HVO_NUL)
Data Item 2 hvac_ord_percent
Measurement Units Values Range Invalid Value
Percent Percent of Full Scale -163.840 ..
163.830
Type: 163.835 Raw:
32,767 (0x7FFF)
Data Item 3 hvac_ord_flow
Measurement Units Values Range Invalid Value
Flow Liters per Second 0 .. 65,534 65,535 (0xFFF)
SNVT_hvac_status
Data Length 7
Suggested Data Array Formats Float
Data Item 1 hvac_sts_mode
Measurement Units Values Range Invalid Value
hvac_t N/A 0 .. 17 255 (0xFF)(HV_NUL)
Data Item 2 hvac_heat_out_pri
Measurement Units Values Range Invalid Value
Primary Heat Output Percent of Full Scale -163.840 ..
163.830
Type: 163.835 Raw:
32,767 (0x7FFF)
Data Item 3 hvac_heat_out_sec
Measurement Units Values Range Invalid Value
Secondary Heat Output Percent of Full Scale -163.840 ..
163.830
Type: 163.835 Raw:
32,767 (0x7FFF)
Data Item 4 hvac_cool_out
Measurement Units Values Range Invalid Value
Cooling Output Percent of Full Scale -163.840 ..
163.830
Type: 163.835 Raw:
32,767 (0x7FFF)
Data Item 5 hvac_econ_out
Measurement Units Values Range Invalid Value
Economizer Output Percent of Full Scale -163.840 ..
163.830
Type: 163.835 Raw:
32,767 (0x7FFF)
Data Item 6 hvac_fan_out
Measurement Units Values Range Invalid Value
Fan Output Percent of Full Scale -163.840 ..
163.830
Type: 163.835 Raw:
32,767 (0x7FFF)
Data Item 7 hvac_in_alarm
Measurement Units Values Range Invalid Value
In Alarm State Alarm value 0 .. 1 N/A
SNVT_hvac_type
Data Length 1
Suggested Data Array Formats Byte, Uint16, Float
Data Item 1
Measurement Units Values Range Invalid Value
Hvac_hvt_t N/A 0 .. 9 255 (0xFF)(HVT_NUL)
SNVT_length
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Length Meters (m) 0 .. 6,553.5 N/A
