SNVT_color
Data Length
3
Suggested Data Array Formats
Float
Data Item 1
L_star
Measurement
Units
Values Range
Invalid Value
Lightness
Lightness
0.0 .. 100.0
N/A
Data Item 2
a_star
Measurement
Units
Values Range
Invalid Value
Redness/Greenness
Redness/Greenness
-200.0 .. 200.0
N/A
Data Item 3
b_star
Measurement
Units
Values Range
Invalid Value
Yellowness/Blueness
Yellowness/Blueness
-200.0 .. 200.0
N/A
SNVT_config_src
Data Length
1
Suggested Data Array Formats
Byte, Uint16, Float
Data Item 1
Measurement
Units
Values Range
Invalid Value
Config_source_t
N/A
0 .. 1
255 (0xFF)(CFG_NUL)
SNVT_count
Data Length
1
Suggested Data Array Formats
Uint16, Float
Data Item 1
Measurement
Units
Values Range
Invalid Value
Event Count
Count
0 .. 65,535
N/A
SNVT_count_f
Data Length
1
Suggested Data Array Formats
Float
Data Item 1
Measurement
Units
Values Range
Invalid Value
Event Count
Count
0 .. 3.40282E38
N/A
SNVT_count_inc
Data Length
1
Suggested Data Array Formats
Sint16, Float
Data Item 1
Measurement
Units
Values Range
Invalid Value
Incremental Count
Count
-32,768 .. 32,767
N/A
SNVT_count_inc_f
Data Length
1
Suggested Data Array Formats
Float
Data Item 1
Measurement
Units
Values Range
Invalid Value
Incremental Count
Count
-3.40282E38
..
3.40282E38
N/A
SNVT_ctrl_req
Data Length
3
Suggested Data Array Formats
Uint16, Float
Data Item 1
ctl_req_rcvr_id
Measurement
Units
Values Range
Invalid Value
Receiver ID
ID number
1 .. 65,535
0
Data Item 2
ctl_req_sndr_id
Measurement
Units
Values Range
Invalid Value
Sender ID
ID number
1 .. 65,534
65,535 (0xFFFF)
Data Item 3
ctl_req_sndr_pri
Measurement
Units
Values Range
Invalid Value
Sender priority
Priority value
0 .. 200
N/A
