FS-8700-21 LonWorks Manual Page 59 of 72
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
SNVT_pH
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Acidity pH -32.768 .. 32.767 N/A
SNVT_pH_f
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Acidity pH -3.40282E38 ..
3.40282E38
N/A
SNVT_pos_ctrl
Data Length 9
Suggested Data Array Formats Float
Data Item 1 pos_ctrl_rcvr_id
Measurement Units Values Range Invalid Value
Receiver ID ID number 1 .. 65,535 0
Data Item 2 pos_ctrl_cntrl_id
Measurement Units Values Range Invalid Value
Controller ID ID number 1 .. 65,534 65,535 (0xFFFF)
Data Item 3 pos_ctrl_cntrl_prio
Measurement Units Values Range Invalid Value
Controller priority Priority value 0 .. 200 N/A
Data Item 4 pos_ctrl_function
Measurement Units Values Range Invalid Value
cam_func_t N/A 0 .. 2 255 (0xFF)(CMF_NUL)
Data Item 5 pos_ctrl_action
Measurement Units Values Range Invalid Value
cam_act_t N/A 0 .. 2 255 (0xFF)(CMA_NUL)
Data Item 6 pos_ctrl_number
Measurement Units Values Range Invalid Value
Action number Action number 1 .. 255 0
Data Item 7 pos_ctrl_pan
Measurement Units Values Range Invalid Value
Pan position Degrees -359.98 .. 360.00 Raw: 32,767 (0x7FFF)
Type: 655.34
Data Item 8 pos_ctrl_tilt
Measurement Units Values Range Invalid Value
Tilt position Degrees -359.98 .. 360.00 Raw: 32,767 (0x7FFF)
Type: 655.34
Data Item 9 pos_ctrl_zoom
Measurement Units Values Range Invalid Value
Zoom position Percent of full-scale or
ppm -163.840 ..
163.830
Raw: 32,767 (0x7FFF)
Type: 163.835
SNVT_power
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Power Watts (W) 0 .. 6,553.5 N/A
SNVT_power_f
Data Length 1
Suggested Data Array Formats Float
Data Item 1
Measurement Units Values Range Invalid Value
Power Watts -3.40282E38 ..
3.40282E38
N/A
