5.3 Host Commands

Table 5.40 Data format of Read Log Ext log page 10h

Byte Item

01 Reserved

02

Status field value

03

Error field value

04

Sector Number field value

05

Cylinder Low field value

06

Cylinder High field value

07

Dev/Head field value

08

Sector Number Exp field value

09

Cylinder Low Exp field value

0A

Cylinder High Exp field value

0B

Sector Count field value

Sector Count Exp field value

0E to FF

Reserved

100 to 1FE Vendor Unique

1FF Check

sum

00 Tag

field

Reserved

0C

0D

Table 5.41 Tag field information

Bit Description

0

… 4

6

7

If bit 7 is 0, this field has an error tag number.

5

Reserved

If this bit is 0, the field consisting of bits 0 to 4 has an
error tag number.

C141-E249

5-149
